| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_127T10_9000006542_55822cztM0_level2.fits | modeM0/AS1A14_127T10_9000006542_55822cztM0_level2_quad_clean.evt |
| Size (bytes) | 535,308,480 | 95,492,160 |
| Size | 510.5 MB | 91.1 MB |
| Events in quadrant A | 6,018,445 | 584,480 |
| Events in quadrant B | 2,973,352 | 697,710 |
| Events in quadrant C | 3,273,254 | 630,190 |
| Events in quadrant D | 7,025,734 | 508,864 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22441 | 2 |
| B | 0 | 14300 | 2 |
| C | 0 | 15204 | 2 |
| D | 0 | 25741 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6751 | 882 | 13.064731% |
| B | 6751 | 69 | 1.022071% |
| C | 6752 | 78 | 1.155213% |
| D | 6752 | 1169 | 17.313389% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7851 | 6752 | 899 | 899 | 11.45% | 13.31% |  |
| B | 7851 | 6752 | 36 | 36 | 0.46% | 0.53% |  |
| C | 7852 | 6753 | 73 | 73 | 0.93% | 1.08% |  |
| D | 7852 | 6753 | 1065 | 1065 | 13.56% | 15.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 115 | 2603483 | 15821.3 | 656 | 640 | 164.5 |
| A | 15 | 32 | 257555 | 1561.65 | 656 | 640 | 164.5 |
| A | 8 | 192 | 181402 | 1098.76 | 656 | 640 | 164.5 |
| B | 5 | 185 | 175999 | 1192.03 | 680 | 657 | 147.1 |
| B | 0 | 199 | 29399 | 195.4 | 680 | 657 | 147.1 |
| B | 0 | 213 | 27301 | 181.13 | 680 | 657 | 147.1 |
| C | 13 | 3 | 535715 | 2835.22 | 674 | 668 | 188.7 |
| C | 15 | 200 | 36741 | 191.15 | 674 | 668 | 188.7 |
| C | 6 | 223 | 21399 | 109.85 | 674 | 668 | 188.7 |
| D | 11 | 129 | 2744524 | 15332.36 | 617 | 589 | 179.0 |
| D | 2 | 62 | 895468 | 5000.34 | 617 | 589 | 179.0 |
| D | 8 | 160 | 689280 | 3848.22 | 617 | 589 | 179.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
