| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_066T02_9000006546_56015cztM0_level2.fits | modeM0/AS1A14_066T02_9000006546_56015cztM0_level2_quad_clean.evt |
| Size (bytes) | 496,598,400 | 94,559,040 |
| Size | 473.6 MB | 90.2 MB |
| Events in quadrant A | 6,097,974 | 555,067 |
| Events in quadrant B | 3,522,006 | 684,010 |
| Events in quadrant C | 4,126,002 | 581,438 |
| Events in quadrant D | 4,108,228 | 568,954 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23080 | 2 |
| B | 0 | 15388 | 2 |
| C | 0 | 17355 | 3 |
| D | 0 | 17072 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6795 | 1032 | 15.187638% |
| B | 6795 | 96 | 1.412804% |
| C | 6794 | 365 | 5.372387% |
| D | 6794 | 168 | 2.472770% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7660 | 6796 | 1072 | 1072 | 13.99% | 15.77% |  |
| B | 7660 | 6796 | 40 | 40 | 0.52% | 0.59% |  |
| C | 7659 | 6795 | 266 | 266 | 3.47% | 3.91% |  |
| D | 7659 | 6795 | 137 | 137 | 1.79% | 2.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 115 | 3024817 | 18116.97 | 676 | 660 | 166.9 |
| A | 15 | 32 | 224390 | 1340.31 | 676 | 660 | 166.9 |
| A | 7 | 64 | 39780 | 234.36 | 676 | 660 | 166.9 |
| B | 4 | 171 | 170373 | 1097.88 | 719 | 693 | 154.6 |
| B | 5 | 185 | 128843 | 829.17 | 719 | 693 | 154.6 |
| B | 10 | 247 | 105815 | 680.17 | 719 | 693 | 154.6 |
| C | 15 | 199 | 662673 | 3511.75 | 684 | 678 | 188.5 |
| C | 13 | 3 | 631863 | 3348.31 | 684 | 678 | 188.5 |
| C | 12 | 250 | 86422 | 454.85 | 684 | 678 | 188.5 |
| D | 8 | 240 | 371530 | 1866.87 | 695 | 664 | 198.7 |
| D | 2 | 249 | 277502 | 1393.55 | 695 | 664 | 198.7 |
| D | 6 | 239 | 224430 | 1126.39 | 695 | 664 | 198.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
