| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T03_9000006548_56037cztM0_level2.fits | modeM0/AS1A14_083T03_9000006548_56037cztM0_level2_quad_clean.evt |
| Size (bytes) | 574,565,760 | 99,740,160 |
| Size | 547.9 MB | 95.1 MB |
| Events in quadrant A | 8,120,615 | 572,730 |
| Events in quadrant B | 3,924,634 | 710,025 |
| Events in quadrant C | 3,420,030 | 644,935 |
| Events in quadrant D | 5,258,161 | 602,660 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28935 | 2 |
| B | 0 | 16580 | 2 |
| C | 0 | 15473 | 9 |
| D | 0 | 20467 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7024 | 1473 | 20.970957% |
| B | 7024 | 251 | 3.573462% |
| C | 7023 | 159 | 2.263990% |
| D | 7023 | 353 | 5.026342% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7874 | 7025 | 1132 | 1132 | 14.38% | 16.11% |  |
| B | 7874 | 7025 | 50 | 50 | 0.64% | 0.71% |  |
| C | 7872 | 7023 | 52 | 52 | 0.66% | 0.74% |  |
| D | 7873 | 7024 | 215 | 215 | 2.73% | 3.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 32 | 4454083 | 25043.06 | 702 | 685 | 177.8 |
| A | 7 | 64 | 590049 | 3314.21 | 702 | 685 | 177.8 |
| A | 12 | 79 | 129841 | 726.29 | 702 | 685 | 177.8 |
| B | 5 | 185 | 606078 | 3800.99 | 742 | 716 | 159.3 |
| B | 0 | 199 | 89616 | 558.19 | 742 | 716 | 159.3 |
| B | 0 | 213 | 87977 | 547.9 | 742 | 716 | 159.3 |
| C | 13 | 3 | 284532 | 1391.73 | 734 | 725 | 203.9 |
| C | 12 | 252 | 85067 | 413.6 | 734 | 725 | 203.9 |
| C | 15 | 199 | 60140 | 291.36 | 734 | 725 | 203.9 |
| D | 11 | 129 | 1389347 | 6554.71 | 731 | 697 | 211.9 |
| D | 2 | 31 | 420345 | 1980.82 | 731 | 697 | 211.9 |
| D | 8 | 160 | 138605 | 650.95 | 731 | 697 | 211.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
