| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T03_9000006548_56072cztM0_level2.fits | modeM0/AS1A14_083T03_9000006548_56072cztM0_level2_quad_clean.evt |
| Size (bytes) | 340,234,560 | 90,826,560 |
| Size | 324.5 MB | 86.6 MB |
| Events in quadrant A | 3,117,595 | 589,055 |
| Events in quadrant B | 3,000,297 | 636,675 |
| Events in quadrant C | 2,884,751 | 564,895 |
| Events in quadrant D | 3,108,107 | 525,938 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13851 | 1 |
| B | 0 | 13415 | 1 |
| C | 0 | 13424 | 1 |
| D | 0 | 14036 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6205 | 126 | 2.030620% |
| B | 6206 | 96 | 1.546890% |
| C | 6206 | 43 | 0.692878% |
| D | 6206 | 74 | 1.192394% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7275 | 6205 | 55 | 55 | 0.76% | 0.89% |  |
| B | 7276 | 6206 | 13 | 13 | 0.18% | 0.21% |  |
| C | 7276 | 6207 | 40 | 40 | 0.55% | 0.64% |  |
| D | 7276 | 6207 | 53 | 53 | 0.73% | 0.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 94 | 189168 | 1154.62 | 654 | 636 | 163.3 |
| A | 3 | 14 | 132989 | 810.57 | 654 | 636 | 163.3 |
| A | 0 | 8 | 70105 | 425.45 | 654 | 636 | 163.3 |
| B | 5 | 185 | 74550 | 533.04 | 651 | 628 | 138.7 |
| B | 0 | 213 | 65681 | 469.09 | 651 | 628 | 138.7 |
| B | 0 | 231 | 57141 | 407.51 | 651 | 628 | 138.7 |
| C | 13 | 3 | 120841 | 698.95 | 627 | 622 | 172.0 |
| C | 12 | 252 | 96908 | 559.81 | 627 | 622 | 172.0 |
| C | 15 | 147 | 50034 | 287.28 | 627 | 622 | 172.0 |
| D | 11 | 129 | 209298 | 1170.49 | 624 | 595 | 178.3 |
| D | 8 | 240 | 118719 | 662.49 | 624 | 595 | 178.3 |
| D | 14 | 52 | 108082 | 602.83 | 624 | 595 | 178.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
