| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T03_9000006548_56142cztM0_level2.fits | modeM0/AS1A14_083T03_9000006548_56142cztM0_level2_quad_clean.evt |
| Size (bytes) | 525,574,080 | 95,238,720 |
| Size | 501.2 MB | 90.8 MB |
| Events in quadrant A | 7,834,752 | 544,815 |
| Events in quadrant B | 3,264,114 | 696,322 |
| Events in quadrant C | 3,530,306 | 616,494 |
| Events in quadrant D | 4,325,999 | 576,833 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27768 | 2 |
| B | 0 | 14172 | 2 |
| C | 0 | 15128 | 2 |
| D | 0 | 17237 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6439 | 1327 | 20.608790% |
| B | 6439 | 131 | 2.034477% |
| C | 6439 | 166 | 2.578040% |
| D | 6439 | 189 | 2.935238% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7564 | 6439 | 1354 | 1354 | 17.90% | 21.03% |  |
| B | 7564 | 6439 | 30 | 30 | 0.40% | 0.47% |  |
| C | 7564 | 6439 | 96 | 96 | 1.27% | 1.49% |  |
| D | 7564 | 6439 | 148 | 148 | 1.96% | 2.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 115 | 4198250 | 25516.67 | 668 | 653 | 164.5 |
| A | 15 | 32 | 551882 | 3350.85 | 668 | 653 | 164.5 |
| A | 3 | 14 | 236390 | 1433.02 | 668 | 653 | 164.5 |
| B | 10 | 247 | 134012 | 883.19 | 709 | 681 | 151.0 |
| B | 5 | 185 | 93322 | 613.66 | 709 | 681 | 151.0 |
| B | 5 | 172 | 86095 | 565.79 | 709 | 681 | 151.0 |
| C | 12 | 254 | 216433 | 1128.37 | 695 | 688 | 191.2 |
| C | 12 | 252 | 198156 | 1032.78 | 695 | 688 | 191.2 |
| C | 15 | 147 | 166051 | 864.87 | 695 | 688 | 191.2 |
| D | 2 | 62 | 660110 | 3336.49 | 694 | 661 | 197.6 |
| D | 11 | 129 | 402841 | 2034.83 | 694 | 661 | 197.6 |
| D | 2 | 31 | 154824 | 779.99 | 694 | 661 | 197.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
