| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_049T01_9000006552_56290cztM0_level2.fits | modeM0/AS1A14_049T01_9000006552_56290cztM0_level2_quad_clean.evt |
| Size (bytes) | 836,493,120 | 79,856,640 |
| Size | 797.7 MB | 76.2 MB |
| Events in quadrant A | 12,583,357 | 308,160 |
| Events in quadrant B | 4,114,878 | 664,219 |
| Events in quadrant C | 8,710,576 | 415,839 |
| Events in quadrant D | 5,042,132 | 568,232 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 41976 | 2 |
| B | 0 | 16685 | 2 |
| C | 0 | 30475 | 2 |
| D | 0 | 19528 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6624 | 3875 | 58.499396% |
| B | 6624 | 486 | 7.336957% |
| C | 6624 | 2506 | 37.832126% |
| D | 6623 | 392 | 5.918768% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7654 | 6624 | 3430 | 3430 | 44.81% | 51.78% |  |
| B | 7654 | 6624 | 223 | 223 | 2.91% | 3.37% |  |
| C | 7654 | 6624 | 2020 | 2020 | 26.39% | 30.50% |  |
| D | 7653 | 6623 | 259 | 259 | 3.38% | 3.91% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 32 | 5253474 | 40071.03 | 529 | 516 | 131.1 |
| A | 7 | 64 | 2237632 | 17065.34 | 529 | 516 | 131.1 |
| A | 14 | 235 | 767664 | 5852.02 | 529 | 516 | 131.1 |
| B | 5 | 172 | 594112 | 3950.62 | 706 | 680 | 150.2 |
| B | 5 | 185 | 257077 | 1706.9 | 706 | 680 | 150.2 |
| B | 0 | 63 | 115385 | 763.62 | 706 | 680 | 150.2 |
| C | 12 | 254 | 4912515 | 31250.51 | 578 | 572 | 157.2 |
| C | 13 | 3 | 689860 | 4385.35 | 578 | 572 | 157.2 |
| C | 5 | 250 | 355837 | 2260.25 | 578 | 572 | 157.2 |
| D | 12 | 31 | 811433 | 4025.46 | 711 | 678 | 201.4 |
| D | 2 | 249 | 542094 | 2688.17 | 711 | 678 | 201.4 |
| D | 8 | 129 | 238273 | 1179.68 | 711 | 678 | 201.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
