| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_060T01_9000006556_56466cztM0_level2.fits | modeM0/AS1A14_060T01_9000006556_56466cztM0_level2_quad_clean.evt |
| Size (bytes) | 851,178,240 | 84,758,400 |
| Size | 811.7 MB | 80.8 MB |
| Events in quadrant A | 16,493,474 | 162,575 |
| Events in quadrant B | 3,516,403 | 726,883 |
| Events in quadrant C | 4,362,503 | 634,130 |
| Events in quadrant D | 6,574,050 | 538,049 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 53751 | 3 |
| B | 0 | 15406 | 3 |
| C | 0 | 18176 | 3 |
| D | 0 | 24503 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7236 | 5669 | 78.344389% |
| B | 7236 | 197 | 2.722499% |
| C | 7236 | 340 | 4.698729% |
| D | 7236 | 997 | 13.778331% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7811 | 7237 | 5381 | 5381 | 68.89% | 74.35% |  |
| B | 7811 | 7239 | 7 | 7 | 0.09% | 0.10% |  |
| C | 7811 | 7239 | 193 | 193 | 2.47% | 2.67% |  |
| D | 7811 | 7238 | 795 | 795 | 10.18% | 10.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 3 | 7087593 | 64638.06 | 437 | 425 | 109.6 |
| A | 4 | 95 | 5463666 | 49827.14 | 437 | 425 | 109.6 |
| A | 12 | 194 | 886884 | 8084.89 | 437 | 425 | 109.6 |
| B | 0 | 63 | 100712 | 588.46 | 795 | 766 | 169.8 |
| B | 5 | 172 | 51473 | 298.55 | 795 | 766 | 169.8 |
| B | 0 | 213 | 44393 | 256.87 | 795 | 766 | 169.8 |
| C | 13 | 3 | 490501 | 2304.21 | 778 | 769 | 212.5 |
| C | 15 | 230 | 460641 | 2163.72 | 778 | 769 | 212.5 |
| C | 6 | 223 | 189927 | 890.0 | 778 | 769 | 212.5 |
| D | 12 | 4 | 2136270 | 10301.91 | 734 | 701 | 207.3 |
| D | 2 | 249 | 547865 | 2639.5 | 734 | 701 | 207.3 |
| D | 8 | 129 | 400952 | 1930.8 | 734 | 701 | 207.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
