| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_060T01_9000006556_56481cztM0_level2.fits | modeM0/AS1A14_060T01_9000006556_56481cztM0_level2_quad_clean.evt |
| Size (bytes) | 594,892,800 | 102,720,960 |
| Size | 567.3 MB | 98.0 MB |
| Events in quadrant A | 6,974,775 | 600,974 |
| Events in quadrant B | 5,207,421 | 693,989 |
| Events in quadrant C | 3,634,501 | 680,659 |
| Events in quadrant D | 5,606,791 | 600,002 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26044 | 2 |
| B | 0 | 20369 | 3 |
| C | 0 | 16581 | 2 |
| D | 0 | 22073 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7685 | 1404 | 18.269356% |
| B | 7684 | 1002 | 13.040083% |
| C | 7684 | 309 | 4.021343% |
| D | 7684 | 746 | 9.708485% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7780 | 7687 | 861 | 861 | 11.07% | 11.20% |  |
| B | 7778 | 7685 | 330 | 330 | 4.24% | 4.29% |  |
| C | 7779 | 7686 | 11 | 11 | 0.14% | 0.14% |  |
| D | 7779 | 7686 | 367 | 367 | 4.72% | 4.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 95 | 1643182 | 8230.92 | 810 | 785 | 199.5 |
| A | 12 | 3 | 1427565 | 7150.35 | 810 | 785 | 199.5 |
| A | 7 | 64 | 222329 | 1110.27 | 810 | 785 | 199.5 |
| B | 5 | 172 | 1494361 | 8193.62 | 843 | 811 | 182.3 |
| B | 0 | 63 | 234162 | 1280.16 | 843 | 811 | 182.3 |
| B | 10 | 247 | 42529 | 228.86 | 843 | 811 | 182.3 |
| C | 12 | 252 | 73197 | 306.75 | 866 | 857 | 235.8 |
| C | 12 | 249 | 49146 | 204.77 | 866 | 857 | 235.8 |
| C | 6 | 223 | 42347 | 175.94 | 866 | 857 | 235.8 |
| D | 2 | 249 | 926485 | 3983.53 | 833 | 795 | 232.4 |
| D | 12 | 4 | 509972 | 2191.15 | 833 | 795 | 232.4 |
| D | 3 | 12 | 221008 | 947.64 | 833 | 795 | 232.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
