| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_060T01_9000006556_56533cztM0_level2.fits | modeM0/AS1A14_060T01_9000006556_56533cztM0_level2_quad_clean.evt |
| Size (bytes) | 520,041,600 | 89,807,040 |
| Size | 496.0 MB | 85.6 MB |
| Events in quadrant A | 4,211,677 | 587,391 |
| Events in quadrant B | 5,682,601 | 592,073 |
| Events in quadrant C | 4,870,937 | 550,620 |
| Events in quadrant D | 3,987,061 | 541,595 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17051 | 1 |
| B | 0 | 21275 | 1 |
| C | 0 | 18942 | 1 |
| D | 0 | 16315 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6411 | 341 | 5.318983% |
| B | 6410 | 858 | 13.385335% |
| C | 6411 | 540 | 8.423023% |
| D | 6411 | 113 | 1.762596% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7466 | 6412 | 376 | 376 | 5.04% | 5.86% |  |
| B | 7465 | 6411 | 630 | 630 | 8.44% | 9.83% |  |
| C | 7466 | 6412 | 594 | 594 | 7.96% | 9.26% |  |
| D | 7466 | 6412 | 133 | 133 | 1.78% | 2.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 95 | 1247963 | 7243.32 | 686 | 667 | 172.2 |
| A | 3 | 14 | 142666 | 824.62 | 686 | 667 | 172.2 |
| A | 4 | 3 | 62514 | 359.16 | 686 | 667 | 172.2 |
| B | 4 | 206 | 1486524 | 10392.11 | 658 | 635 | 143.0 |
| B | 4 | 171 | 542657 | 3790.83 | 658 | 635 | 143.0 |
| B | 0 | 213 | 331307 | 2312.68 | 658 | 635 | 143.0 |
| C | 15 | 230 | 1363522 | 7626.62 | 648 | 644 | 178.7 |
| C | 12 | 252 | 511004 | 2855.96 | 648 | 644 | 178.7 |
| C | 14 | 254 | 391575 | 2187.64 | 648 | 644 | 178.7 |
| D | 8 | 240 | 872052 | 4619.28 | 661 | 631 | 188.6 |
| D | 3 | 12 | 87941 | 462.82 | 661 | 631 | 188.6 |
| D | 8 | 129 | 77490 | 407.42 | 661 | 631 | 188.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
