| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_060T01_9000006556_56534cztM0_level2.fits | modeM0/AS1A14_060T01_9000006556_56534cztM0_level2_quad_clean.evt |
| Size (bytes) | 413,389,440 | 91,195,200 |
| Size | 394.2 MB | 87.0 MB |
| Events in quadrant A | 3,338,404 | 597,308 |
| Events in quadrant B | 4,247,716 | 632,588 |
| Events in quadrant C | 3,639,252 | 569,162 |
| Events in quadrant D | 3,596,637 | 530,725 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14280 | 1 |
| B | 0 | 16916 | 1 |
| C | 0 | 15195 | 1 |
| D | 0 | 15021 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6178 | 90 | 1.456782% |
| B | 6179 | 294 | 4.758051% |
| C | 6179 | 170 | 2.751254% |
| D | 6179 | 116 | 1.877326% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7328 | 6179 | 87 | 87 | 1.19% | 1.41% |  |
| B | 7328 | 6179 | 225 | 225 | 3.07% | 3.64% |  |
| C | 7328 | 6179 | 163 | 163 | 2.22% | 2.64% |  |
| D | 7328 | 6179 | 109 | 109 | 1.49% | 1.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 95 | 407064 | 2437.42 | 670 | 651 | 166.7 |
| A | 0 | 12 | 111163 | 662.78 | 670 | 651 | 166.7 |
| A | 3 | 22 | 56660 | 335.91 | 670 | 651 | 166.7 |
| B | 4 | 171 | 638878 | 4468.68 | 662 | 637 | 142.8 |
| B | 0 | 63 | 304120 | 2124.85 | 662 | 637 | 142.8 |
| B | 0 | 213 | 178981 | 1248.69 | 662 | 637 | 142.8 |
| C | 12 | 252 | 766407 | 4293.54 | 646 | 639 | 178.4 |
| C | 6 | 223 | 132152 | 737.37 | 646 | 639 | 178.4 |
| C | 14 | 254 | 94002 | 523.47 | 646 | 639 | 178.4 |
| D | 2 | 249 | 558024 | 3039.72 | 641 | 613 | 183.4 |
| D | 8 | 160 | 89470 | 484.56 | 641 | 613 | 183.4 |
| D | 11 | 129 | 73324 | 396.51 | 641 | 613 | 183.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
