| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T06_9000006558_56637cztM0_level2.fits | modeM0/AS1A14_083T06_9000006558_56637cztM0_level2_quad_clean.evt |
| Size (bytes) | 400,536,000 | 94,104,000 |
| Size | 382.0 MB | 89.7 MB |
| Events in quadrant A | 3,667,003 | 620,417 |
| Events in quadrant B | 3,202,622 | 673,926 |
| Events in quadrant C | 3,733,032 | 575,405 |
| Events in quadrant D | 3,735,235 | 541,353 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15321 | 1 |
| B | 0 | 13674 | 1 |
| C | 0 | 15594 | 1 |
| D | 0 | 15530 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6279 | 142 | 2.261507% |
| B | 6279 | 54 | 0.860010% |
| C | 6279 | 180 | 2.866699% |
| D | 6280 | 203 | 3.232484% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7474 | 6280 | 112 | 112 | 1.50% | 1.78% |  |
| B | 7474 | 6280 | 15 | 15 | 0.20% | 0.24% |  |
| C | 7474 | 6280 | 171 | 171 | 2.29% | 2.72% |  |
| D | 7475 | 6281 | 174 | 174 | 2.33% | 2.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 249 | 460162 | 2724.96 | 681 | 665 | 168.6 |
| A | 4 | 95 | 190040 | 1123.05 | 681 | 665 | 168.6 |
| A | 6 | 179 | 164599 | 972.18 | 681 | 665 | 168.6 |
| B | 4 | 21 | 246161 | 1688.98 | 679 | 656 | 145.4 |
| B | 0 | 197 | 78942 | 538.58 | 679 | 656 | 145.4 |
| B | 4 | 141 | 39259 | 265.57 | 679 | 656 | 145.4 |
| C | 14 | 96 | 398820 | 2267.68 | 639 | 633 | 175.6 |
| C | 1 | 16 | 283340 | 1610.02 | 639 | 633 | 175.6 |
| C | 13 | 3 | 264808 | 1504.48 | 639 | 633 | 175.6 |
| D | 6 | 239 | 436269 | 2385.64 | 642 | 612 | 182.6 |
| D | 2 | 249 | 384117 | 2100.06 | 642 | 612 | 182.6 |
| D | 2 | 31 | 113098 | 615.97 | 642 | 612 | 182.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
