| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T03_9000006562_56835cztM0_level2.fits | modeM0/AS1A14_083T03_9000006562_56835cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,061,953,280 | 239,601,600 |
| Size | 1.9 GB | 228.5 MB |
| Events in quadrant A | 17,598,113 | 1,719,082 |
| Events in quadrant B | 15,010,286 | 1,736,673 |
| Events in quadrant C | 30,683,727 | 951,453 |
| Events in quadrant D | 11,553,256 | 1,522,493 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 392 | 0 |
| B | 0 | 392 | 0 |
| C | 0 | 392 | 0 |
| D | 0 | 392 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 65921 | 4 |
| B | 0 | 57793 | 4 |
| C | 0 | 104281 | 18 |
| D | 0 | 48383 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19208 | 757 | 3.941066% |
| B | 19209 | 2131 | 11.093758% |
| C | 19207 | 8922 | 46.451814% |
| D | 19209 | 793 | 4.128273% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20428 | 19213 | 208 | 208 | 1.02% | 1.08% |  |
| B | 20429 | 19213 | 1147 | 1147 | 5.61% | 5.97% |  |
| C | 20429 | 19212 | 8250 | 8250 | 40.38% | 42.94% |  |
| D | 20429 | 19214 | 502 | 502 | 2.46% | 2.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 8644701 | 17317.85 | 2027 | 1975 | 499.1 |
| A | 10 | 251 | 481459 | 960.76 | 2027 | 1975 | 499.1 |
| A | 7 | 64 | 356644 | 710.67 | 2027 | 1975 | 499.1 |
| B | 5 | 185 | 5402646 | 13106.51 | 1945 | 1877 | 412.1 |
| B | 5 | 172 | 536324 | 1296.99 | 1945 | 1877 | 412.1 |
| B | 10 | 16 | 385121 | 930.05 | 1945 | 1877 | 412.1 |
| C | 12 | 249 | 21714138 | 52147.53 | 1536 | 1522 | 416.4 |
| C | 8 | 208 | 520366 | 1246.12 | 1536 | 1522 | 416.4 |
| C | 13 | 3 | 411488 | 984.62 | 1536 | 1522 | 416.4 |
| D | 8 | 240 | 1710846 | 3119.72 | 1965 | 1880 | 547.8 |
| D | 2 | 249 | 961921 | 1752.56 | 1965 | 1880 | 547.8 |
| D | 2 | 31 | 726500 | 1322.8 | 1965 | 1880 | 547.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
