| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T03_9000006562_56857cztM0_level2.fits | modeM0/AS1A14_083T03_9000006562_56857cztM0_level2_quad_clean.evt |
| Size (bytes) | 458,144,640 | 86,011,200 |
| Size | 436.9 MB | 82.0 MB |
| Events in quadrant A | 4,881,419 | 519,695 |
| Events in quadrant B | 3,171,536 | 616,947 |
| Events in quadrant C | 3,853,479 | 550,653 |
| Events in quadrant D | 4,581,795 | 494,898 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18854 | 1 |
| B | 0 | 13905 | 1 |
| C | 0 | 16009 | 1 |
| D | 0 | 17791 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6049 | 852 | 14.084973% |
| B | 6049 | 214 | 3.537775% |
| C | 6049 | 244 | 4.033725% |
| D | 6050 | 526 | 8.694215% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7053 | 6048 | 747 | 747 | 10.59% | 12.35% |  |
| B | 7054 | 6049 | 79 | 79 | 1.12% | 1.31% |  |
| C | 7054 | 6050 | 227 | 227 | 3.22% | 3.75% |  |
| D | 7055 | 6051 | 447 | 447 | 6.34% | 7.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 62 | 2266513 | 14658.86 | 624 | 609 | 154.6 |
| A | 3 | 46 | 96153 | 618.1 | 624 | 609 | 154.6 |
| A | 10 | 251 | 30025 | 190.3 | 624 | 609 | 154.6 |
| B | 10 | 16 | 242615 | 1749.53 | 638 | 615 | 138.3 |
| B | 10 | 32 | 106798 | 767.64 | 638 | 615 | 138.3 |
| B | 5 | 185 | 78132 | 560.41 | 638 | 615 | 138.3 |
| C | 13 | 3 | 1134993 | 6583.12 | 625 | 619 | 172.3 |
| C | 15 | 208 | 81371 | 468.63 | 625 | 619 | 172.3 |
| C | 12 | 252 | 67540 | 388.36 | 625 | 619 | 172.3 |
| D | 2 | 249 | 1016804 | 5862.96 | 613 | 584 | 173.3 |
| D | 8 | 240 | 532891 | 3071.08 | 613 | 584 | 173.3 |
| D | 0 | 160 | 192330 | 1106.25 | 613 | 584 | 173.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
