| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T10_9000006566_57059cztM0_level2.fits | modeM0/AS1A14_083T10_9000006566_57059cztM0_level2_quad_clean.evt |
| Size (bytes) | 393,367,680 | 98,637,120 |
| Size | 375.1 MB | 94.1 MB |
| Events in quadrant A | 3,119,206 | 652,982 |
| Events in quadrant B | 3,459,705 | 686,930 |
| Events in quadrant C | 3,238,436 | 627,445 |
| Events in quadrant D | 4,245,286 | 572,622 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13803 | 2 |
| B | 0 | 14695 | 2 |
| C | 0 | 14034 | 2 |
| D | 0 | 16895 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6405 | 87 | 1.358314% |
| B | 6406 | 292 | 4.558227% |
| C | 6406 | 68 | 1.061505% |
| D | 6406 | 247 | 3.855760% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7605 | 6406 | 43 | 43 | 0.57% | 0.67% |  |
| B | 7606 | 6406 | 150 | 150 | 1.97% | 2.34% |  |
| C | 7606 | 6407 | 20 | 20 | 0.26% | 0.31% |  |
| D | 7606 | 6407 | 211 | 211 | 2.77% | 3.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 187628 | 1056.79 | 720 | 704 | 176.9 |
| A | 3 | 245 | 37527 | 208.18 | 720 | 704 | 176.9 |
| A | 4 | 207 | 33201 | 183.72 | 720 | 704 | 176.9 |
| B | 10 | 16 | 481896 | 3269.81 | 698 | 672 | 147.2 |
| B | 0 | 63 | 60458 | 406.23 | 698 | 672 | 147.2 |
| B | 0 | 213 | 59123 | 397.16 | 698 | 672 | 147.2 |
| C | 15 | 209 | 153293 | 803.38 | 706 | 700 | 189.9 |
| C | 14 | 254 | 115267 | 603.18 | 706 | 700 | 189.9 |
| C | 6 | 223 | 58636 | 305.02 | 706 | 700 | 189.9 |
| D | 15 | 142 | 696592 | 3506.2 | 692 | 659 | 198.5 |
| D | 12 | 33 | 338440 | 1701.78 | 692 | 659 | 198.5 |
| D | 7 | 96 | 144942 | 726.92 | 692 | 659 | 198.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
