| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T10_9000006566_57062cztM0_level2.fits | modeM0/AS1A14_083T10_9000006566_57062cztM0_level2_quad_clean.evt |
| Size (bytes) | 517,034,880 | 97,986,240 |
| Size | 493.1 MB | 93.4 MB |
| Events in quadrant A | 3,142,714 | 655,474 |
| Events in quadrant B | 3,547,798 | 691,975 |
| Events in quadrant C | 3,439,108 | 638,188 |
| Events in quadrant D | 8,466,754 | 495,066 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14589 | 1 |
| B | 0 | 15702 | 1 |
| C | 0 | 15266 | 1 |
| D | 0 | 30034 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6979 | 177 | 2.536180% |
| B | 6979 | 329 | 4.714142% |
| C | 6980 | 170 | 2.435530% |
| D | 6980 | 1448 | 20.744986% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7484 | 6979 | 5 | 5 | 0.07% | 0.07% |  |
| B | 7484 | 6979 | 105 | 105 | 1.40% | 1.50% |  |
| C | 7485 | 6981 | 32 | 32 | 0.43% | 0.46% |  |
| D | 7485 | 6981 | 1284 | 1284 | 17.15% | 18.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 75561 | 400.97 | 766 | 746 | 186.6 |
| A | 4 | 3 | 26883 | 140.08 | 766 | 746 | 186.6 |
| A | 8 | 6 | 25230 | 131.22 | 766 | 746 | 186.6 |
| B | 10 | 16 | 414107 | 2644.66 | 734 | 706 | 156.3 |
| B | 0 | 63 | 90267 | 572.95 | 734 | 706 | 156.3 |
| B | 10 | 32 | 36768 | 230.7 | 734 | 706 | 156.3 |
| C | 6 | 223 | 156993 | 761.4 | 750 | 742 | 205.2 |
| C | 1 | 16 | 107034 | 517.95 | 750 | 742 | 205.2 |
| C | 15 | 209 | 72780 | 351.03 | 750 | 742 | 205.2 |
| D | 15 | 142 | 4496261 | 23058.82 | 685 | 652 | 195.0 |
| D | 12 | 33 | 865337 | 4435.13 | 685 | 652 | 195.0 |
| D | 8 | 240 | 197074 | 1007.49 | 685 | 652 | 195.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
