| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T10_9000006566_57112cztM0_level2.fits | modeM0/AS1A14_083T10_9000006566_57112cztM0_level2_quad_clean.evt |
| Size (bytes) | 715,115,520 | 86,088,960 |
| Size | 682.0 MB | 82.1 MB |
| Events in quadrant A | 3,413,274 | 637,298 |
| Events in quadrant B | 4,836,682 | 620,517 |
| Events in quadrant C | 8,320,692 | 379,447 |
| Events in quadrant D | 9,383,069 | 504,042 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14999 | 1 |
| B | 0 | 19152 | 1 |
| C | 0 | 29291 | 1 |
| D | 0 | 32559 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6676 | 68 | 1.018574% |
| B | 6677 | 629 | 9.420398% |
| C | 6677 | 2753 | 41.231092% |
| D | 6676 | 977 | 14.634512% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7476 | 6677 | 32 | 32 | 0.43% | 0.48% |  |
| B | 7477 | 6678 | 389 | 389 | 5.20% | 5.83% |  |
| C | 7477 | 6678 | 2277 | 2277 | 30.45% | 34.10% |  |
| D | 7476 | 6677 | 1094 | 1094 | 14.63% | 16.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 159 | 263635 | 1476.48 | 715 | 697 | 178.1 |
| A | 10 | 251 | 122147 | 681.98 | 715 | 697 | 178.1 |
| A | 4 | 95 | 96852 | 539.94 | 715 | 697 | 178.1 |
| B | 10 | 16 | 1081476 | 7422.26 | 676 | 652 | 145.6 |
| B | 5 | 185 | 756112 | 5187.91 | 676 | 652 | 145.6 |
| B | 4 | 171 | 66474 | 452.01 | 676 | 652 | 145.6 |
| C | 15 | 198 | 5936583 | 42362.1 | 507 | 502 | 140.1 |
| C | 12 | 252 | 202544 | 1441.85 | 507 | 502 | 140.1 |
| C | 12 | 254 | 72476 | 513.63 | 507 | 502 | 140.1 |
| D | 15 | 142 | 5423899 | 28821.89 | 657 | 625 | 188.2 |
| D | 12 | 33 | 503507 | 2672.56 | 657 | 625 | 188.2 |
| D | 8 | 160 | 489508 | 2598.16 | 657 | 625 | 188.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
