| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_070T08_9000006568_57159cztM0_level2.fits | modeM0/AS1A14_070T08_9000006568_57159cztM0_level2_quad_clean.evt |
| Size (bytes) | 546,039,360 | 90,394,560 |
| Size | 520.7 MB | 86.2 MB |
| Events in quadrant A | 2,788,467 | 648,978 |
| Events in quadrant B | 3,922,814 | 670,489 |
| Events in quadrant C | 8,525,817 | 402,901 |
| Events in quadrant D | 4,469,382 | 560,921 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13288 | 2 |
| B | 0 | 16315 | 2 |
| C | 0 | 29884 | 2 |
| D | 0 | 17844 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6508 | 18 | 0.276583% |
| B | 6508 | 245 | 3.764597% |
| C | 6508 | 2421 | 37.200369% |
| D | 6507 | 212 | 3.258030% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7598 | 6509 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7598 | 6509 | 153 | 153 | 2.01% | 2.35% |  |
| C | 7598 | 6508 | 1974 | 1974 | 25.98% | 30.33% |  |
| D | 7597 | 6508 | 170 | 170 | 2.24% | 2.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 36977 | 209.58 | 697 | 680 | 173.2 |
| A | 10 | 251 | 25309 | 142.21 | 697 | 680 | 173.2 |
| A | 10 | 248 | 9574 | 51.36 | 697 | 680 | 173.2 |
| B | 10 | 16 | 503677 | 3463.1 | 679 | 655 | 145.3 |
| B | 8 | 128 | 233354 | 1602.04 | 679 | 655 | 145.3 |
| B | 0 | 199 | 110774 | 758.12 | 679 | 655 | 145.3 |
| C | 15 | 198 | 5182176 | 34654.22 | 542 | 536 | 149.5 |
| C | 13 | 3 | 705722 | 4716.2 | 542 | 536 | 149.5 |
| C | 15 | 224 | 385989 | 2577.86 | 542 | 536 | 149.5 |
| D | 12 | 33 | 1181256 | 6263.61 | 656 | 624 | 188.5 |
| D | 8 | 160 | 138583 | 731.91 | 656 | 624 | 188.5 |
| D | 3 | 12 | 117109 | 617.99 | 656 | 624 | 188.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
