| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_049T03_9000006570_57292cztM0_level2.fits | modeM0/AS1A14_049T03_9000006570_57292cztM0_level2_quad_clean.evt |
| Size (bytes) | 472,276,800 | 89,827,200 |
| Size | 450.4 MB | 85.7 MB |
| Events in quadrant A | 3,096,964 | 610,753 |
| Events in quadrant B | 3,060,590 | 652,625 |
| Events in quadrant C | 4,235,369 | 557,479 |
| Events in quadrant D | 6,617,100 | 475,064 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13350 | 129 |
| B | 0 | 13516 | 148 |
| C | 0 | 16952 | 210 |
| D | 0 | 24110 | 289 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 2 |
| C | 0 | 124 | 2 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6084 | 28 | 0.460224% |
| B | 6077 | 76 | 1.250617% |
| C | 6074 | 256 | 4.214686% |
| D | 6057 | 967 | 15.964999% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7358 | 6129 | 6 | 6 | 0.08% | 0.10% |  |
| B | 7358 | 6131 | 38 | 38 | 0.52% | 0.62% |  |
| C | 7359 | 6126 | 221 | 221 | 3.00% | 3.61% |  |
| D | 7359 | 6133 | 865 | 865 | 11.75% | 14.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 4 | 385562 | 2349.3 | 662 | 645 | 163.8 |
| A | 3 | 14 | 96444 | 584.7 | 662 | 645 | 163.8 |
| A | 4 | 13 | 17687 | 104.01 | 662 | 645 | 163.8 |
| B | 5 | 185 | 152380 | 1078.41 | 655 | 631 | 140.7 |
| B | 0 | 63 | 69634 | 490.37 | 655 | 631 | 140.7 |
| B | 7 | 252 | 66767 | 470.0 | 655 | 631 | 140.7 |
| C | 15 | 224 | 1369775 | 7973.92 | 624 | 619 | 171.7 |
| C | 6 | 223 | 105724 | 612.13 | 624 | 619 | 171.7 |
| C | 14 | 254 | 73109 | 422.18 | 624 | 619 | 171.7 |
| D | 3 | 224 | 3754378 | 22193.33 | 593 | 565 | 169.1 |
| D | 3 | 12 | 249985 | 1474.62 | 593 | 565 | 169.1 |
| D | 8 | 240 | 74994 | 440.04 | 593 | 565 | 169.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
