| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_102T01_9000006572_57368cztM0_level2.fits | modeM0/AS1A14_102T01_9000006572_57368cztM0_level2_quad_clean.evt |
| Size (bytes) | 545,348,160 | 96,471,360 |
| Size | 520.1 MB | 92.0 MB |
| Events in quadrant A | 3,677,647 | 659,737 |
| Events in quadrant B | 4,054,070 | 655,547 |
| Events in quadrant C | 7,088,170 | 548,901 |
| Events in quadrant D | 4,778,189 | 528,780 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16358 | 2 |
| B | 0 | 17477 | 2 |
| C | 0 | 26415 | 2 |
| D | 0 | 19833 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7583 | 93 | 1.226428% |
| B | 7583 | 319 | 4.206778% |
| C | 7583 | 906 | 11.947778% |
| D | 7583 | 415 | 5.472768% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7982 | 7858 | 7 | 7 | 0.09% | 0.09% |  |
| B | 7982 | 7858 | 87 | 87 | 1.09% | 1.11% |  |
| C | 7982 | 7858 | 698 | 698 | 8.74% | 8.88% |  |
| D | 7982 | 7858 | 390 | 390 | 4.89% | 4.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 283653 | 1376.09 | 835 | 812 | 205.5 |
| A | 8 | 4 | 50783 | 243.12 | 835 | 812 | 205.5 |
| A | 0 | 12 | 32467 | 154.01 | 835 | 812 | 205.5 |
| B | 5 | 185 | 356975 | 2039.05 | 810 | 779 | 174.7 |
| B | 10 | 16 | 216777 | 1236.48 | 810 | 779 | 174.7 |
| B | 7 | 252 | 56360 | 318.17 | 810 | 779 | 174.7 |
| C | 15 | 224 | 3457773 | 16729.76 | 762 | 754 | 206.6 |
| C | 14 | 254 | 142376 | 685.36 | 762 | 754 | 206.6 |
| C | 12 | 2 | 140359 | 675.6 | 762 | 754 | 206.6 |
| D | 8 | 240 | 970814 | 4367.6 | 785 | 750 | 222.1 |
| D | 6 | 159 | 193307 | 866.97 | 785 | 750 | 222.1 |
| D | 3 | 12 | 110897 | 495.92 | 785 | 750 | 222.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
