| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_113T09_9000006574_57467cztM0_level2.fits | modeM0/AS1A14_113T09_9000006574_57467cztM0_level2_quad_clean.evt |
| Size (bytes) | 549,383,040 | 94,328,640 |
| Size | 523.9 MB | 90.0 MB |
| Events in quadrant A | 3,013,434 | 656,147 |
| Events in quadrant B | 5,185,051 | 622,948 |
| Events in quadrant C | 6,688,181 | 543,660 |
| Events in quadrant D | 4,936,978 | 573,424 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13509 | 1 |
| B | 0 | 19821 | 1 |
| C | 0 | 24588 | 1 |
| D | 0 | 19115 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6602 | 74 | 1.120872% |
| B | 6603 | 887 | 13.433288% |
| C | 6602 | 1069 | 16.192063% |
| D | 6602 | 333 | 5.043926% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7687 | 6603 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7688 | 6604 | 565 | 565 | 7.35% | 8.56% |  |
| C | 7687 | 6603 | 759 | 759 | 9.87% | 11.49% |  |
| D | 7687 | 6603 | 235 | 235 | 3.06% | 3.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 153 | 124899 | 690.72 | 737 | 718 | 179.8 |
| A | 4 | 3 | 15300 | 81.11 | 737 | 718 | 179.8 |
| A | 3 | 14 | 13547 | 71.36 | 737 | 718 | 179.8 |
| B | 4 | 206 | 2220221 | 15264.57 | 678 | 655 | 145.4 |
| B | 10 | 247 | 64854 | 441.51 | 678 | 655 | 145.4 |
| B | 8 | 234 | 51066 | 346.69 | 678 | 655 | 145.4 |
| C | 15 | 224 | 2003083 | 11220.05 | 656 | 650 | 178.5 |
| C | 12 | 254 | 1287514 | 7210.57 | 656 | 650 | 178.5 |
| C | 9 | 38 | 281694 | 1574.75 | 656 | 650 | 178.5 |
| D | 7 | 96 | 483068 | 2429.43 | 698 | 666 | 198.6 |
| D | 15 | 142 | 450470 | 2265.26 | 698 | 666 | 198.6 |
| D | 2 | 249 | 398810 | 2005.1 | 698 | 666 | 198.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
