| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_113T09_9000006574_57468cztM0_level2.fits | modeM0/AS1A14_113T09_9000006574_57468cztM0_level2_quad_clean.evt |
| Size (bytes) | 592,943,040 | 76,933,440 |
| Size | 565.5 MB | 73.4 MB |
| Events in quadrant A | 2,660,979 | 571,476 |
| Events in quadrant B | 7,349,018 | 427,180 |
| Events in quadrant C | 7,075,750 | 424,555 |
| Events in quadrant D | 4,404,740 | 493,835 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12058 | 1 |
| B | 0 | 25900 | 1 |
| C | 0 | 25229 | 1 |
| D | 0 | 17240 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5898 | 41 | 0.695151% |
| B | 5899 | 1999 | 33.887100% |
| C | 5899 | 1497 | 25.377183% |
| D | 5899 | 361 | 6.119681% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6833 | 5899 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6834 | 5900 | 1409 | 1409 | 20.62% | 23.88% |  |
| C | 6834 | 5900 | 994 | 994 | 14.54% | 16.85% |  |
| D | 6834 | 5900 | 289 | 289 | 4.23% | 4.90% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 153 | 134456 | 847.55 | 642 | 625 | 157.9 |
| A | 4 | 3 | 20613 | 126.58 | 642 | 625 | 157.9 |
| A | 3 | 14 | 10169 | 60.44 | 642 | 625 | 157.9 |
| B | 4 | 206 | 5059841 | 44958.48 | 520 | 500 | 112.5 |
| B | 0 | 63 | 65259 | 575.46 | 520 | 500 | 112.5 |
| B | 10 | 247 | 30208 | 263.99 | 520 | 500 | 112.5 |
| C | 12 | 254 | 3097678 | 21077.16 | 536 | 532 | 146.9 |
| C | 15 | 224 | 1660176 | 11294.46 | 536 | 532 | 146.9 |
| C | 14 | 254 | 156716 | 1062.89 | 536 | 532 | 146.9 |
| D | 2 | 249 | 756309 | 4461.19 | 601 | 573 | 169.4 |
| D | 8 | 240 | 358992 | 2115.79 | 601 | 573 | 169.4 |
| D | 7 | 96 | 348576 | 2054.3 | 601 | 573 | 169.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
