| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_113T09_9000006574_57551cztM0_level2.fits | modeM0/AS1A14_113T09_9000006574_57551cztM0_level2_quad_clean.evt |
| Size (bytes) | 537,281,280 | 92,882,880 |
| Size | 512.4 MB | 88.6 MB |
| Events in quadrant A | 2,951,587 | 651,661 |
| Events in quadrant B | 3,446,542 | 691,984 |
| Events in quadrant C | 4,719,050 | 603,688 |
| Events in quadrant D | 8,261,191 | 407,131 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13479 | 2 |
| B | 0 | 14583 | 2 |
| C | 0 | 18519 | 2 |
| D | 0 | 29024 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6560 | 46 | 0.701220% |
| B | 6560 | 130 | 1.981707% |
| C | 6560 | 299 | 4.557927% |
| D | 6560 | 2025 | 30.868902% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7630 | 6560 | 10 | 10 | 0.13% | 0.15% |  |
| B | 7630 | 6560 | 59 | 59 | 0.77% | 0.90% |  |
| C | 7630 | 6560 | 240 | 240 | 3.15% | 3.66% |  |
| D | 7629 | 6559 | 2015 | 2015 | 26.41% | 30.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 68683 | 381.81 | 725 | 707 | 178.0 |
| A | 8 | 249 | 22502 | 122.42 | 725 | 707 | 178.0 |
| A | 4 | 249 | 21829 | 118.64 | 725 | 707 | 178.0 |
| B | 4 | 206 | 151385 | 987.01 | 715 | 687 | 152.7 |
| B | 4 | 142 | 144301 | 940.61 | 715 | 687 | 152.7 |
| B | 7 | 252 | 78630 | 510.49 | 715 | 687 | 152.7 |
| C | 15 | 224 | 1443992 | 7584.11 | 700 | 691 | 190.3 |
| C | 12 | 254 | 307658 | 1613.02 | 700 | 691 | 190.3 |
| C | 12 | 252 | 67901 | 353.17 | 700 | 691 | 190.3 |
| D | 15 | 142 | 4511635 | 27494.72 | 579 | 552 | 164.1 |
| D | 8 | 160 | 921741 | 5614.58 | 579 | 552 | 164.1 |
| D | 8 | 240 | 246635 | 1499.86 | 579 | 552 | 164.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
