| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_070T08_9000006576_57567cztM0_level2.fits | modeM0/AS1A14_070T08_9000006576_57567cztM0_level2_quad_clean.evt |
| Size (bytes) | 419,918,400 | 88,323,840 |
| Size | 400.5 MB | 84.2 MB |
| Events in quadrant A | 2,640,318 | 595,747 |
| Events in quadrant B | 2,934,279 | 642,253 |
| Events in quadrant C | 5,504,520 | 511,748 |
| Events in quadrant D | 4,007,440 | 513,629 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12063 | 1 |
| B | 0 | 12688 | 1 |
| C | 0 | 20456 | 1 |
| D | 0 | 15889 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5880 | 33 | 0.561224% |
| B | 5880 | 64 | 1.088435% |
| C | 5880 | 817 | 13.894558% |
| D | 5880 | 340 | 5.782313% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7065 | 5881 | 12 | 12 | 0.17% | 0.20% |  |
| B | 7065 | 5881 | 34 | 34 | 0.48% | 0.58% |  |
| C | 7065 | 5881 | 719 | 719 | 10.18% | 12.23% |  |
| D | 7065 | 5881 | 249 | 249 | 3.52% | 4.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 71254 | 439.35 | 651 | 634 | 160.7 |
| A | 3 | 128 | 27094 | 164.62 | 651 | 634 | 160.7 |
| A | 4 | 3 | 11701 | 68.85 | 651 | 634 | 160.7 |
| B | 10 | 247 | 75086 | 542.91 | 641 | 617 | 137.2 |
| B | 8 | 128 | 58771 | 423.97 | 641 | 617 | 137.2 |
| B | 15 | 69 | 57211 | 412.59 | 641 | 617 | 137.2 |
| C | 15 | 224 | 2790573 | 17164.87 | 598 | 590 | 162.5 |
| C | 14 | 254 | 162389 | 995.44 | 598 | 590 | 162.5 |
| C | 12 | 254 | 62604 | 381.53 | 598 | 590 | 162.5 |
| D | 15 | 142 | 753679 | 4309.6 | 622 | 594 | 174.7 |
| D | 7 | 96 | 264110 | 1508.0 | 622 | 594 | 174.7 |
| D | 8 | 160 | 141981 | 809.1 | 622 | 594 | 174.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
