| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_070T08_9000006576_57569cztM0_level2.fits | modeM0/AS1A14_070T08_9000006576_57569cztM0_level2_quad_clean.evt |
| Size (bytes) | 478,431,360 | 103,947,840 |
| Size | 456.3 MB | 99.1 MB |
| Events in quadrant A | 3,697,295 | 689,682 |
| Events in quadrant B | 3,789,771 | 729,993 |
| Events in quadrant C | 4,080,852 | 658,831 |
| Events in quadrant D | 5,600,587 | 583,477 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15978 | 2 |
| B | 0 | 16211 | 2 |
| C | 0 | 17028 | 3 |
| D | 0 | 21347 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6968 | 86 | 1.234214% |
| B | 6969 | 275 | 3.946047% |
| C | 6968 | 197 | 2.827210% |
| D | 6968 | 586 | 8.409874% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8013 | 6969 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8014 | 6970 | 90 | 90 | 1.12% | 1.29% |  |
| C | 8013 | 6969 | 91 | 91 | 1.14% | 1.31% |  |
| D | 8013 | 6969 | 496 | 496 | 6.19% | 7.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 12 | 611887 | 3207.44 | 772 | 752 | 190.5 |
| A | 12 | 3 | 25429 | 129.51 | 772 | 752 | 190.5 |
| A | 3 | 14 | 20869 | 105.58 | 772 | 752 | 190.5 |
| B | 5 | 185 | 553220 | 3480.85 | 749 | 719 | 158.7 |
| B | 4 | 201 | 40142 | 248.37 | 749 | 719 | 158.7 |
| B | 10 | 247 | 35102 | 216.62 | 749 | 719 | 158.7 |
| C | 15 | 224 | 887939 | 4390.58 | 744 | 735 | 202.1 |
| C | 14 | 254 | 92657 | 454.9 | 744 | 735 | 202.1 |
| C | 12 | 254 | 55095 | 269.02 | 744 | 735 | 202.1 |
| D | 15 | 142 | 895754 | 4359.95 | 726 | 692 | 205.3 |
| D | 8 | 160 | 705863 | 3434.97 | 726 | 692 | 205.3 |
| D | 8 | 240 | 395089 | 1921.15 | 726 | 692 | 205.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
