| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_070T08_9000006576_57570cztM0_level2.fits | modeM0/AS1A14_070T08_9000006576_57570cztM0_level2_quad_clean.evt |
| Size (bytes) | 407,612,160 | 92,977,920 |
| Size | 388.7 MB | 88.7 MB |
| Events in quadrant A | 2,770,283 | 614,865 |
| Events in quadrant B | 3,465,672 | 636,243 |
| Events in quadrant C | 4,201,040 | 571,353 |
| Events in quadrant D | 4,157,486 | 549,679 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13114 | 1 |
| B | 0 | 14908 | 1 |
| C | 0 | 17173 | 1 |
| D | 0 | 16802 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6347 | 93 | 1.465259% |
| B | 6347 | 247 | 3.891602% |
| C | 6347 | 381 | 6.002836% |
| D | 6347 | 235 | 3.702537% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7138 | 6348 | 6 | 6 | 0.08% | 0.09% |  |
| B | 7138 | 6348 | 98 | 98 | 1.37% | 1.54% |  |
| C | 7138 | 6348 | 273 | 273 | 3.82% | 4.30% |  |
| D | 7138 | 6348 | 176 | 176 | 2.47% | 2.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 25709 | 146.73 | 686 | 667 | 170.7 |
| A | 3 | 14 | 25025 | 142.73 | 686 | 667 | 170.7 |
| A | 4 | 95 | 17274 | 97.31 | 686 | 667 | 170.7 |
| B | 5 | 185 | 554170 | 3960.13 | 661 | 636 | 139.8 |
| B | 7 | 252 | 64726 | 458.52 | 661 | 636 | 139.8 |
| B | 10 | 247 | 40315 | 283.87 | 661 | 636 | 139.8 |
| C | 15 | 224 | 1412737 | 8035.17 | 646 | 639 | 175.7 |
| C | 12 | 254 | 110525 | 625.28 | 646 | 639 | 175.7 |
| C | 14 | 254 | 86031 | 485.9 | 646 | 639 | 175.7 |
| D | 7 | 253 | 520474 | 2766.41 | 657 | 626 | 187.9 |
| D | 8 | 160 | 225258 | 1195.4 | 657 | 626 | 187.9 |
| D | 15 | 142 | 133300 | 706.03 | 657 | 626 | 187.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
