| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_070T08_9000006576_57582cztM0_level2.fits | modeM0/AS1A14_070T08_9000006576_57582cztM0_level2_quad_clean.evt |
| Size (bytes) | 440,343,360 | 92,427,840 |
| Size | 419.9 MB | 88.1 MB |
| Events in quadrant A | 2,652,879 | 622,363 |
| Events in quadrant B | 3,048,310 | 671,018 |
| Events in quadrant C | 5,339,478 | 563,240 |
| Events in quadrant D | 4,787,860 | 518,616 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12285 | 1 |
| B | 0 | 13192 | 1 |
| C | 0 | 20017 | 1 |
| D | 0 | 18396 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6064 | 26 | 0.428760% |
| B | 6065 | 76 | 1.253092% |
| C | 6065 | 535 | 8.821105% |
| D | 6064 | 510 | 8.410290% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7254 | 6065 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7255 | 6066 | 30 | 30 | 0.41% | 0.49% |  |
| C | 7255 | 6066 | 395 | 395 | 5.44% | 6.51% |  |
| D | 7254 | 6065 | 442 | 442 | 6.09% | 7.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 22938 | 134.94 | 675 | 656 | 165.1 |
| A | 3 | 128 | 10580 | 60.1 | 675 | 656 | 165.1 |
| A | 3 | 137 | 7921 | 44.0 | 675 | 656 | 165.1 |
| B | 2 | 249 | 293371 | 2074.73 | 664 | 639 | 141.1 |
| B | 10 | 247 | 26927 | 186.32 | 664 | 639 | 141.1 |
| B | 7 | 252 | 22111 | 152.18 | 664 | 639 | 141.1 |
| C | 12 | 254 | 1743781 | 9984.66 | 636 | 628 | 174.6 |
| C | 15 | 224 | 663929 | 3799.34 | 636 | 628 | 174.6 |
| C | 14 | 254 | 277601 | 1586.48 | 636 | 628 | 174.6 |
| D | 15 | 142 | 1433813 | 7964.33 | 631 | 601 | 180.0 |
| D | 8 | 160 | 372749 | 2068.02 | 631 | 601 | 180.0 |
| D | 2 | 249 | 237266 | 1315.14 | 631 | 601 | 180.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
