| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_125T09_9000006578_57679cztM0_level2.fits | modeM0/AS1A14_125T09_9000006578_57679cztM0_level2_quad_clean.evt |
| Size (bytes) | 450,492,480 | 97,899,840 |
| Size | 429.6 MB | 93.4 MB |
| Events in quadrant A | 2,897,291 | 650,058 |
| Events in quadrant B | 3,555,247 | 685,308 |
| Events in quadrant C | 4,828,890 | 597,797 |
| Events in quadrant D | 4,863,687 | 555,647 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13891 | 2 |
| B | 0 | 15467 | 2 |
| C | 0 | 19025 | 2 |
| D | 0 | 19334 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6823 | 29 | 0.425033% |
| B | 6823 | 176 | 2.579510% |
| C | 6823 | 312 | 4.572769% |
| D | 6823 | 414 | 6.067712% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7688 | 6823 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7688 | 6823 | 62 | 62 | 0.81% | 0.91% |  |
| C | 7688 | 6823 | 275 | 275 | 3.58% | 4.03% |  |
| D | 7688 | 6824 | 417 | 417 | 5.42% | 6.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 17461 | 93.13 | 733 | 716 | 179.8 |
| A | 4 | 95 | 14896 | 78.87 | 733 | 716 | 179.8 |
| A | 13 | 248 | 9258 | 47.51 | 733 | 716 | 179.8 |
| B | 10 | 16 | 215317 | 1397.46 | 720 | 695 | 153.6 |
| B | 5 | 185 | 155633 | 1008.84 | 720 | 695 | 153.6 |
| B | 4 | 80 | 149493 | 968.86 | 720 | 695 | 153.6 |
| C | 15 | 224 | 1463542 | 7787.57 | 691 | 683 | 187.8 |
| C | 12 | 252 | 389503 | 2069.89 | 691 | 683 | 187.8 |
| C | 14 | 254 | 125263 | 663.21 | 691 | 683 | 187.8 |
| D | 8 | 240 | 1089839 | 5532.94 | 687 | 656 | 196.9 |
| D | 8 | 160 | 525976 | 2668.57 | 687 | 656 | 196.9 |
| D | 3 | 12 | 341827 | 1733.12 | 687 | 656 | 196.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
