| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T16_9000006580_57815cztM0_level2.fits | modeM0/AS1A14_083T16_9000006580_57815cztM0_level2_quad_clean.evt |
| Size (bytes) | 660,384,000 | 78,678,720 |
| Size | 629.8 MB | 75.0 MB |
| Events in quadrant A | 9,154,335 | 383,070 |
| Events in quadrant B | 2,943,086 | 635,405 |
| Events in quadrant C | 8,170,987 | 418,362 |
| Events in quadrant D | 3,689,258 | 506,413 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31523 | 2 |
| B | 0 | 13339 | 3 |
| C | 0 | 28614 | 2 |
| D | 0 | 15656 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6289 | 2461 | 39.131817% |
| B | 6288 | 53 | 0.842875% |
| C | 6288 | 1562 | 24.840967% |
| D | 6288 | 225 | 3.578244% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7778 | 6560 | 2209 | 2209 | 28.40% | 33.67% |  |
| B | 7777 | 6563 | 14 | 14 | 0.18% | 0.21% |  |
| C | 7777 | 6531 | 1428 | 1428 | 18.36% | 21.86% |  |
| D | 7777 | 6563 | 167 | 167 | 2.15% | 2.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 5408617 | 44237.92 | 492 | 479 | 122.3 |
| A | 3 | 14 | 1368262 | 11188.3 | 492 | 479 | 122.3 |
| A | 10 | 251 | 379743 | 3102.33 | 492 | 479 | 122.3 |
| B | 4 | 142 | 49356 | 342.22 | 672 | 648 | 142.3 |
| B | 7 | 252 | 41142 | 284.51 | 672 | 648 | 142.3 |
| B | 9 | 251 | 37377 | 258.06 | 672 | 648 | 142.3 |
| C | 9 | 38 | 5126505 | 31416.34 | 597 | 591 | 163.2 |
| C | 15 | 224 | 557399 | 3412.63 | 597 | 591 | 163.2 |
| C | 12 | 2 | 98857 | 602.26 | 597 | 591 | 163.2 |
| D | 2 | 249 | 550310 | 3062.03 | 637 | 609 | 179.5 |
| D | 8 | 240 | 146242 | 811.23 | 637 | 609 | 179.5 |
| D | 8 | 160 | 133117 | 738.12 | 637 | 609 | 179.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
