| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_083T16_9000006580_57816cztM0_level2.fits | modeM0/AS1A14_083T16_9000006580_57816cztM0_level2_quad_clean.evt |
| Size (bytes) | 559,140,480 | 93,839,040 |
| Size | 533.2 MB | 89.5 MB |
| Events in quadrant A | 5,397,461 | 578,018 |
| Events in quadrant B | 3,387,794 | 685,593 |
| Events in quadrant C | 7,848,736 | 536,602 |
| Events in quadrant D | 3,523,748 | 556,067 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20960 | 2 |
| B | 0 | 15134 | 2 |
| C | 0 | 28223 | 2 |
| D | 0 | 15625 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6957 | 767 | 11.024867% |
| B | 6958 | 76 | 1.092268% |
| C | 6958 | 965 | 13.868928% |
| D | 6958 | 83 | 1.192872% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9587 | 7234 | 663 | 663 | 6.92% | 9.17% |  |
| B | 9588 | 7235 | 25 | 25 | 0.26% | 0.35% |  |
| C | 9588 | 7235 | 761 | 761 | 7.94% | 10.52% |  |
| D | 9588 | 7235 | 38 | 38 | 0.40% | 0.53% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 1351753 | 7672.97 | 702 | 684 | 176.1 |
| A | 3 | 14 | 1102844 | 6259.37 | 702 | 684 | 176.1 |
| A | 3 | 128 | 118241 | 667.63 | 702 | 684 | 176.1 |
| B | 4 | 142 | 124562 | 792.49 | 743 | 717 | 156.3 |
| B | 9 | 251 | 58536 | 369.99 | 743 | 717 | 156.3 |
| B | 0 | 63 | 48597 | 306.39 | 743 | 717 | 156.3 |
| C | 9 | 38 | 3253737 | 17678.97 | 678 | 670 | 184.0 |
| C | 15 | 224 | 1473092 | 8001.96 | 678 | 670 | 184.0 |
| C | 12 | 2 | 339293 | 1840.27 | 678 | 670 | 184.0 |
| D | 3 | 224 | 217819 | 1069.45 | 715 | 681 | 203.0 |
| D | 3 | 12 | 147785 | 724.52 | 715 | 681 | 203.0 |
| D | 2 | 153 | 82008 | 400.55 | 715 | 681 | 203.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
