| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_125T11_9000006582_57844cztM0_level2.fits | modeM0/AS1A14_125T11_9000006582_57844cztM0_level2_quad_clean.evt |
| Size (bytes) | 444,392,640 | 87,903,360 |
| Size | 423.8 MB | 83.8 MB |
| Events in quadrant A | 2,728,918 | 584,696 |
| Events in quadrant B | 3,244,983 | 622,780 |
| Events in quadrant C | 6,812,619 | 509,035 |
| Events in quadrant D | 3,169,759 | 502,165 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13027 | 2 |
| B | 0 | 14373 | 2 |
| C | 0 | 24635 | 8 |
| D | 0 | 14130 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6351 | 16 | 0.251929% |
| B | 6351 | 158 | 2.487797% |
| C | 6350 | 739 | 11.637795% |
| D | 6350 | 70 | 1.102362% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7819 | 6630 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7819 | 6630 | 98 | 98 | 1.25% | 1.48% |  |
| C | 7817 | 6628 | 630 | 630 | 8.06% | 9.51% |  |
| D | 7818 | 6629 | 57 | 57 | 0.73% | 0.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 245 | 52303 | 306.58 | 682 | 666 | 168.4 |
| A | 3 | 128 | 12194 | 68.44 | 682 | 666 | 168.4 |
| A | 3 | 137 | 8258 | 45.08 | 682 | 666 | 168.4 |
| B | 5 | 185 | 429463 | 3003.55 | 673 | 649 | 142.8 |
| B | 7 | 252 | 33750 | 231.85 | 673 | 649 | 142.8 |
| B | 12 | 111 | 17116 | 115.34 | 673 | 649 | 142.8 |
| C | 9 | 38 | 3477070 | 20198.94 | 630 | 623 | 172.1 |
| C | 15 | 224 | 769100 | 4465.02 | 630 | 623 | 172.1 |
| C | 12 | 2 | 38018 | 217.27 | 630 | 623 | 172.1 |
| D | 2 | 153 | 192694 | 1037.7 | 651 | 620 | 185.1 |
| D | 12 | 110 | 127334 | 684.59 | 651 | 620 | 185.1 |
| D | 8 | 160 | 89873 | 482.2 | 651 | 620 | 185.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
