| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_125T11_9000006582_57870cztM0_level2.fits | modeM0/AS1A14_125T11_9000006582_57870cztM0_level2_quad_clean.evt |
| Size (bytes) | 521,835,840 | 91,797,120 |
| Size | 497.7 MB | 87.5 MB |
| Events in quadrant A | 2,741,295 | 629,634 |
| Events in quadrant B | 4,647,692 | 621,262 |
| Events in quadrant C | 7,302,092 | 512,350 |
| Events in quadrant D | 4,122,108 | 563,910 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13111 | 1 |
| B | 0 | 18366 | 1 |
| C | 0 | 26217 | 1 |
| D | 0 | 16633 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6484 | 10 | 0.154226% |
| B | 6483 | 518 | 7.990128% |
| C | 6484 | 1098 | 16.933991% |
| D | 6484 | 27 | 0.416410% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7473 | 6484 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7472 | 6483 | 419 | 419 | 5.61% | 6.46% |  |
| C | 7474 | 6485 | 1120 | 1120 | 14.99% | 17.27% |  |
| D | 7474 | 6485 | 16 | 16 | 0.21% | 0.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 245 | 14982 | 82.89 | 698 | 682 | 172.5 |
| A | 7 | 64 | 9935 | 53.64 | 698 | 682 | 172.5 |
| A | 4 | 3 | 9595 | 51.67 | 698 | 682 | 172.5 |
| B | 5 | 172 | 1578289 | 11008.8 | 665 | 640 | 143.3 |
| B | 4 | 158 | 185681 | 1291.21 | 665 | 640 | 143.3 |
| B | 5 | 185 | 50852 | 350.38 | 665 | 640 | 143.3 |
| C | 15 | 224 | 1936079 | 11298.77 | 623 | 618 | 171.3 |
| C | 2 | 12 | 1545115 | 9016.41 | 623 | 618 | 171.3 |
| C | 9 | 38 | 1081435 | 6309.56 | 623 | 618 | 171.3 |
| D | 12 | 110 | 1121052 | 5903.54 | 667 | 638 | 189.8 |
| D | 2 | 153 | 110605 | 579.42 | 667 | 638 | 189.8 |
| D | 2 | 31 | 101891 | 533.51 | 667 | 638 | 189.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
