| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_125T11_9000006582_57889cztM0_level2.fits | modeM0/AS1A14_125T11_9000006582_57889cztM0_level2_quad_clean.evt |
| Size (bytes) | 497,309,760 | 91,059,840 |
| Size | 474.3 MB | 86.8 MB |
| Events in quadrant A | 2,739,742 | 642,157 |
| Events in quadrant B | 3,299,145 | 679,383 |
| Events in quadrant C | 3,370,732 | 596,361 |
| Events in quadrant D | 8,491,096 | 384,247 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13261 | 2 |
| B | 0 | 14454 | 2 |
| C | 0 | 14924 | 3 |
| D | 0 | 29980 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6526 | 27 | 0.413730% |
| B | 6526 | 125 | 1.915415% |
| C | 6525 | 96 | 1.471264% |
| D | 6525 | 2182 | 33.440613% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7616 | 6527 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7616 | 6527 | 49 | 49 | 0.64% | 0.75% |  |
| C | 7615 | 6526 | 70 | 70 | 0.92% | 1.07% |  |
| D | 7615 | 6525 | 2082 | 2082 | 27.34% | 31.91% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 16898 | 94.07 | 696 | 678 | 172.4 |
| A | 3 | 245 | 10091 | 54.59 | 696 | 678 | 172.4 |
| A | 7 | 64 | 10021 | 54.19 | 696 | 678 | 172.4 |
| B | 5 | 172 | 305578 | 2076.04 | 686 | 662 | 146.9 |
| B | 7 | 252 | 60806 | 409.49 | 686 | 662 | 146.9 |
| B | 10 | 247 | 55065 | 370.41 | 686 | 662 | 146.9 |
| C | 15 | 224 | 592634 | 3272.17 | 666 | 661 | 180.9 |
| C | 14 | 254 | 70156 | 384.14 | 666 | 661 | 180.9 |
| C | 6 | 223 | 46954 | 255.89 | 666 | 661 | 180.9 |
| D | 12 | 110 | 5167955 | 32072.03 | 565 | 537 | 161.1 |
| D | 8 | 160 | 492215 | 3051.64 | 565 | 537 | 161.1 |
| D | 8 | 240 | 277050 | 1716.2 | 565 | 537 | 161.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
