| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_125T11_9000006582_57900cztM0_level2.fits | modeM0/AS1A14_125T11_9000006582_57900cztM0_level2_quad_clean.evt |
| Size (bytes) | 448,709,760 | 95,016,960 |
| Size | 427.9 MB | 90.6 MB |
| Events in quadrant A | 2,857,924 | 640,093 |
| Events in quadrant B | 3,379,569 | 669,509 |
| Events in quadrant C | 3,323,760 | 599,822 |
| Events in quadrant D | 6,547,304 | 517,642 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13183 | 1 |
| B | 0 | 14694 | 1 |
| C | 0 | 14504 | 1 |
| D | 0 | 24066 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6446 | 23 | 0.356810% |
| B | 6446 | 175 | 2.714862% |
| C | 6446 | 72 | 1.116972% |
| D | 6446 | 743 | 11.526528% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7516 | 6447 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7516 | 6447 | 111 | 111 | 1.48% | 1.72% |  |
| C | 7516 | 6447 | 63 | 63 | 0.84% | 0.98% |  |
| D | 7516 | 6447 | 777 | 777 | 10.34% | 12.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 95227 | 543.42 | 703 | 684 | 174.0 |
| A | 4 | 236 | 24712 | 138.11 | 703 | 684 | 174.0 |
| A | 3 | 14 | 18023 | 99.66 | 703 | 684 | 174.0 |
| B | 5 | 172 | 341480 | 2342.57 | 684 | 659 | 145.5 |
| B | 5 | 185 | 99004 | 675.96 | 684 | 659 | 145.5 |
| B | 7 | 252 | 41276 | 279.17 | 684 | 659 | 145.5 |
| C | 15 | 224 | 458603 | 2506.35 | 667 | 661 | 182.7 |
| C | 12 | 252 | 83679 | 454.36 | 667 | 661 | 182.7 |
| C | 14 | 67 | 66846 | 362.24 | 667 | 661 | 182.7 |
| D | 8 | 160 | 2510027 | 13456.23 | 651 | 620 | 186.5 |
| D | 2 | 120 | 1069787 | 5733.21 | 651 | 620 | 186.5 |
| D | 8 | 240 | 241113 | 1289.6 | 651 | 620 | 186.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
