| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_125T11_9000006582_57928cztM0_level2.fits | modeM0/AS1A14_125T11_9000006582_57928cztM0_level2_quad_clean.evt |
| Size (bytes) | 444,147,840 | 97,992,000 |
| Size | 423.6 MB | 93.5 MB |
| Events in quadrant A | 2,888,558 | 655,971 |
| Events in quadrant B | 4,720,164 | 651,251 |
| Events in quadrant C | 3,761,678 | 622,623 |
| Events in quadrant D | 4,561,054 | 580,114 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13388 | 1 |
| B | 0 | 18492 | 2 |
| C | 0 | 15807 | 1 |
| D | 0 | 18194 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6552 | 53 | 0.808913% |
| B | 6551 | 524 | 7.998779% |
| C | 6551 | 119 | 1.816517% |
| D | 6551 | 301 | 4.594718% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7491 | 6551 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7491 | 6551 | 398 | 398 | 5.31% | 6.08% |  |
| C | 7490 | 6550 | 93 | 93 | 1.24% | 1.42% |  |
| D | 7491 | 6551 | 316 | 316 | 4.22% | 4.82% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 66568 | 371.78 | 717 | 700 | 177.2 |
| A | 3 | 14 | 26291 | 144.45 | 717 | 700 | 177.2 |
| A | 3 | 245 | 13290 | 71.06 | 717 | 700 | 177.2 |
| B | 3 | 238 | 1677486 | 11454.53 | 683 | 656 | 146.4 |
| B | 4 | 142 | 51929 | 350.25 | 683 | 656 | 146.4 |
| B | 6 | 51 | 49533 | 333.88 | 683 | 656 | 146.4 |
| C | 15 | 224 | 704677 | 3708.49 | 686 | 678 | 189.8 |
| C | 14 | 254 | 175152 | 919.09 | 686 | 678 | 189.8 |
| C | 2 | 12 | 75779 | 395.61 | 686 | 678 | 189.8 |
| D | 2 | 62 | 710649 | 3614.07 | 687 | 656 | 196.5 |
| D | 12 | 110 | 659232 | 3352.34 | 687 | 656 | 196.5 |
| D | 2 | 31 | 152831 | 774.62 | 687 | 656 | 196.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
