| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_125T11_9000006582_57931cztM0_level2.fits | modeM0/AS1A14_125T11_9000006582_57931cztM0_level2_quad_clean.evt |
| Size (bytes) | 409,826,880 | 94,878,720 |
| Size | 390.8 MB | 90.5 MB |
| Events in quadrant A | 2,737,096 | 639,285 |
| Events in quadrant B | 3,847,646 | 666,133 |
| Events in quadrant C | 4,530,509 | 576,179 |
| Events in quadrant D | 3,566,624 | 552,905 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12777 | 2 |
| B | 0 | 15929 | 2 |
| C | 0 | 17877 | 2 |
| D | 0 | 15139 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6280 | 19 | 0.302548% |
| B | 6280 | 200 | 3.184713% |
| C | 6280 | 340 | 5.414013% |
| D | 6279 | 203 | 3.232999% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7490 | 6281 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7490 | 6281 | 91 | 91 | 1.21% | 1.45% |  |
| C | 7490 | 6281 | 313 | 313 | 4.18% | 4.98% |  |
| D | 7489 | 6280 | 170 | 170 | 2.27% | 2.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 28885 | 165.8 | 689 | 674 | 170.1 |
| A | 3 | 14 | 21673 | 123.41 | 689 | 674 | 170.1 |
| A | 3 | 137 | 8225 | 44.38 | 689 | 674 | 170.1 |
| B | 3 | 238 | 580661 | 4047.15 | 673 | 648 | 143.3 |
| B | 0 | 171 | 146507 | 1017.76 | 673 | 648 | 143.3 |
| B | 0 | 63 | 122382 | 849.42 | 673 | 648 | 143.3 |
| C | 15 | 224 | 1897657 | 10754.9 | 642 | 635 | 176.4 |
| C | 14 | 254 | 47909 | 268.01 | 642 | 635 | 176.4 |
| C | 9 | 237 | 21778 | 119.87 | 642 | 635 | 176.4 |
| D | 8 | 240 | 285424 | 1558.32 | 648 | 618 | 182.8 |
| D | 12 | 110 | 278810 | 1522.13 | 648 | 618 | 182.8 |
| D | 8 | 160 | 95244 | 517.75 | 648 | 618 | 182.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
