| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57943cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57943cztM0_level2_quad_clean.evt |
| Size (bytes) | 415,748,160 | 97,202,880 |
| Size | 396.5 MB | 92.7 MB |
| Events in quadrant A | 2,977,598 | 652,868 |
| Events in quadrant B | 3,401,561 | 693,608 |
| Events in quadrant C | 4,734,922 | 557,476 |
| Events in quadrant D | 3,760,312 | 577,952 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13597 | 1 |
| B | 0 | 14808 | 1 |
| C | 0 | 18723 | 1 |
| D | 0 | 15658 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6618 | 54 | 0.815956% |
| B | 6619 | 125 | 1.888503% |
| C | 6619 | 757 | 11.436773% |
| D | 6618 | 135 | 2.039891% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7633 | 6619 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7634 | 6620 | 38 | 38 | 0.50% | 0.57% |  |
| C | 7633 | 6619 | 376 | 376 | 4.93% | 5.68% |  |
| D | 7633 | 6619 | 107 | 107 | 1.40% | 1.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 30249 | 161.11 | 742 | 723 | 183.3 |
| A | 3 | 14 | 24915 | 132.01 | 742 | 723 | 183.3 |
| A | 13 | 254 | 12901 | 66.45 | 742 | 723 | 183.3 |
| B | 4 | 201 | 71521 | 454.6 | 725 | 700 | 155.8 |
| B | 0 | 153 | 61560 | 390.66 | 725 | 700 | 155.8 |
| B | 10 | 247 | 59097 | 374.85 | 725 | 700 | 155.8 |
| C | 1 | 12 | 1187954 | 6572.17 | 660 | 654 | 180.7 |
| C | 15 | 224 | 562166 | 3108.19 | 660 | 654 | 180.7 |
| C | 14 | 254 | 227339 | 1254.79 | 660 | 654 | 180.7 |
| D | 3 | 176 | 331094 | 1655.7 | 713 | 683 | 199.6 |
| D | 2 | 249 | 244407 | 1221.31 | 713 | 683 | 199.6 |
| D | 8 | 240 | 109791 | 546.74 | 713 | 683 | 199.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
