| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57955cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57955cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,748,969,280 | 344,868,480 |
| Size | 1.6 GB | 328.9 MB |
| Events in quadrant A | 11,640,494 | 2,274,889 |
| Events in quadrant B | 11,947,999 | 2,448,198 |
| Events in quadrant C | 15,797,622 | 2,141,111 |
| Events in quadrant D | 23,458,040 | 1,889,273 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 52240 | 3 |
| B | 0 | 52672 | 3 |
| C | 0 | 64092 | 3 |
| D | 0 | 87032 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 496 | 0 |
| B | 0 | 496 | 0 |
| C | 0 | 496 | 0 |
| D | 0 | 496 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 24538 | 628 | 2.559296% |
| B | 24539 | 714 | 2.909654% |
| C | 24539 | 993 | 4.046620% |
| D | 24538 | 2730 | 11.125601% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 26293 | 24542 | 83 | 83 | 0.32% | 0.34% |  |
| B | 26294 | 24543 | 67 | 67 | 0.25% | 0.27% |  |
| C | 26294 | 24543 | 477 | 477 | 1.81% | 1.94% |  |
| D | 26293 | 24541 | 2082 | 2082 | 7.92% | 8.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 3 | 275057 | 411.18 | 2714 | 2644 | 662.5 |
| A | 6 | 161 | 217885 | 324.88 | 2714 | 2644 | 662.5 |
| A | 3 | 245 | 210159 | 313.22 | 2714 | 2644 | 662.5 |
| B | 0 | 213 | 240754 | 415.88 | 2666 | 2560 | 572.7 |
| B | 10 | 128 | 223313 | 385.43 | 2666 | 2560 | 572.7 |
| B | 5 | 185 | 187843 | 323.5 | 2666 | 2560 | 572.7 |
| C | 15 | 224 | 3120552 | 4429.55 | 2609 | 2589 | 703.9 |
| C | 1 | 16 | 1291720 | 1831.41 | 2609 | 2589 | 703.9 |
| C | 14 | 254 | 381842 | 538.79 | 2609 | 2589 | 703.9 |
| D | 12 | 110 | 8869857 | 12525.39 | 2523 | 2411 | 708.0 |
| D | 2 | 249 | 3176966 | 4484.1 | 2523 | 2411 | 708.0 |
| D | 8 | 240 | 546385 | 768.37 | 2523 | 2411 | 708.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
