| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57958cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57958cztM0_level2_quad_clean.evt |
| Size (bytes) | 480,948,480 | 97,735,680 |
| Size | 458.7 MB | 93.2 MB |
| Events in quadrant A | 3,285,390 | 660,486 |
| Events in quadrant B | 3,683,151 | 689,985 |
| Events in quadrant C | 3,805,857 | 613,245 |
| Events in quadrant D | 6,516,724 | 536,546 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14302 | 2 |
| B | 0 | 15489 | 1 |
| C | 0 | 15941 | 1 |
| D | 0 | 24021 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6590 | 61 | 0.925645% |
| B | 6591 | 241 | 3.656501% |
| C | 6591 | 168 | 2.548930% |
| D | 6591 | 684 | 10.377788% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7655 | 6591 | 10 | 10 | 0.13% | 0.15% |  |
| B | 7656 | 6592 | 143 | 143 | 1.87% | 2.17% |  |
| C | 7656 | 6592 | 106 | 106 | 1.38% | 1.61% |  |
| D | 7656 | 6592 | 526 | 526 | 6.87% | 7.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 227846 | 1230.0 | 746 | 726 | 184.7 |
| A | 3 | 245 | 60134 | 321.73 | 746 | 726 | 184.7 |
| A | 10 | 248 | 48724 | 259.94 | 746 | 726 | 184.7 |
| B | 10 | 246 | 474195 | 3055.19 | 723 | 695 | 155.0 |
| B | 10 | 247 | 55537 | 353.86 | 723 | 695 | 155.0 |
| B | 6 | 51 | 49687 | 316.11 | 723 | 695 | 155.0 |
| C | 15 | 224 | 867715 | 4423.19 | 711 | 703 | 196.0 |
| C | 6 | 223 | 47582 | 239.16 | 711 | 703 | 196.0 |
| C | 14 | 254 | 38837 | 194.54 | 711 | 703 | 196.0 |
| D | 12 | 110 | 2568435 | 13120.72 | 692 | 662 | 195.7 |
| D | 2 | 249 | 772087 | 3941.8 | 692 | 662 | 195.7 |
| D | 8 | 240 | 105074 | 533.52 | 692 | 662 | 195.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
