| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57959cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57959cztM0_level2_quad_clean.evt |
| Size (bytes) | 481,642,560 | 98,147,520 |
| Size | 459.3 MB | 93.6 MB |
| Events in quadrant A | 3,119,826 | 665,314 |
| Events in quadrant B | 3,244,885 | 710,086 |
| Events in quadrant C | 3,915,637 | 620,262 |
| Events in quadrant D | 7,040,931 | 520,280 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13766 | 2 |
| B | 0 | 14151 | 2 |
| C | 0 | 16322 | 3 |
| D | 0 | 25373 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6534 | 58 | 0.887665% |
| B | 6534 | 96 | 1.469238% |
| C | 6533 | 178 | 2.724629% |
| D | 6533 | 901 | 13.791520% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7689 | 6535 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7689 | 6535 | 25 | 25 | 0.33% | 0.38% |  |
| C | 7688 | 6533 | 134 | 134 | 1.74% | 2.05% |  |
| D | 7688 | 6534 | 758 | 758 | 9.86% | 11.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 66397 | 358.74 | 746 | 727 | 183.1 |
| A | 10 | 248 | 61608 | 332.58 | 746 | 727 | 183.1 |
| A | 3 | 245 | 38742 | 207.67 | 746 | 727 | 183.1 |
| B | 10 | 247 | 102704 | 642.99 | 731 | 704 | 158.6 |
| B | 5 | 185 | 43188 | 267.81 | 731 | 704 | 158.6 |
| B | 7 | 252 | 29738 | 183.02 | 731 | 704 | 158.6 |
| C | 15 | 224 | 1031067 | 5313.61 | 706 | 698 | 193.9 |
| C | 6 | 223 | 50325 | 255.93 | 706 | 698 | 193.9 |
| C | 12 | 252 | 24222 | 121.31 | 706 | 698 | 193.9 |
| D | 12 | 110 | 3341785 | 17118.58 | 681 | 651 | 195.2 |
| D | 2 | 249 | 474132 | 2425.92 | 681 | 651 | 195.2 |
| D | 3 | 12 | 102197 | 520.28 | 681 | 651 | 195.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
