| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57966cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57966cztM0_level2_quad_clean.evt |
| Size (bytes) | 917,435,520 | 105,134,400 |
| Size | 874.9 MB | 100.3 MB |
| Events in quadrant A | 11,815,411 | 507,260 |
| Events in quadrant B | 4,482,331 | 833,729 |
| Events in quadrant C | 4,192,389 | 738,988 |
| Events in quadrant D | 12,829,839 | 527,351 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40995 | 4 |
| B | 0 | 19036 | 0 |
| C | 0 | 18595 | 0 |
| D | 0 | 43899 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 166 | 0 |
| B | 0 | 166 | 0 |
| C | 0 | 166 | 0 |
| D | 0 | 166 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8283 | 3171 | 38.283231% |
| B | 8283 | 234 | 2.825063% |
| C | 8283 | 80 | 0.965834% |
| D | 8284 | 2389 | 28.838725% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8282 | 8282 | 2610 | 2610 | 31.51% | 31.51% |  |
| B | 8283 | 8283 | 96 | 96 | 1.16% | 1.16% |  |
| C | 8283 | 8283 | 51 | 51 | 0.62% | 0.62% |  |
| D | 8284 | 8284 | 2093 | 2093 | 25.27% | 25.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 8723808 | 45610.8 | 776 | 756 | 191.2 |
| A | 13 | 248 | 37082 | 189.94 | 776 | 756 | 191.2 |
| A | 3 | 245 | 33577 | 171.61 | 776 | 756 | 191.2 |
| B | 7 | 252 | 293411 | 1468.12 | 915 | 879 | 199.3 |
| B | 10 | 246 | 148045 | 738.58 | 915 | 879 | 199.3 |
| B | 6 | 51 | 101238 | 503.67 | 915 | 879 | 199.3 |
| C | 15 | 224 | 414324 | 1669.42 | 905 | 898 | 247.6 |
| C | 12 | 252 | 75494 | 301.22 | 905 | 898 | 247.6 |
| C | 14 | 254 | 61881 | 246.25 | 905 | 898 | 247.6 |
| D | 12 | 110 | 9013046 | 38953.82 | 820 | 782 | 231.4 |
| D | 12 | 251 | 172609 | 742.69 | 820 | 782 | 231.4 |
| D | 8 | 240 | 171367 | 737.32 | 820 | 782 | 231.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
