| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57972cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57972cztM0_level2_quad_clean.evt |
| Size (bytes) | 816,379,200 | 79,439,040 |
| Size | 778.6 MB | 75.8 MB |
| Events in quadrant A | 6,366,815 | 572,116 |
| Events in quadrant B | 3,583,274 | 674,361 |
| Events in quadrant C | 4,645,687 | 564,501 |
| Events in quadrant D | 15,122,384 | 142,517 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23304 | 1 |
| B | 0 | 15126 | 1 |
| C | 0 | 18372 | 1 |
| D | 0 | 49241 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6468 | 937 | 14.486704% |
| B | 6469 | 142 | 2.195084% |
| C | 6469 | 509 | 7.868295% |
| D | 6469 | 5122 | 79.177616% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7473 | 6468 | 751 | 751 | 10.05% | 11.61% |  |
| B | 7474 | 6469 | 52 | 52 | 0.70% | 0.80% |  |
| C | 7474 | 6469 | 405 | 405 | 5.42% | 6.26% |  |
| D | 7473 | 6468 | 4961 | 4961 | 66.39% | 76.70% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 3559732 | 20794.07 | 691 | 673 | 171.2 |
| A | 7 | 64 | 47378 | 272.88 | 691 | 673 | 171.2 |
| A | 3 | 14 | 29967 | 171.15 | 691 | 673 | 171.2 |
| B | 10 | 128 | 189577 | 1234.18 | 708 | 681 | 153.1 |
| B | 6 | 51 | 155211 | 1009.64 | 708 | 681 | 153.1 |
| B | 5 | 185 | 65260 | 421.93 | 708 | 681 | 153.1 |
| C | 15 | 224 | 1686513 | 9101.06 | 671 | 666 | 185.2 |
| C | 6 | 223 | 147408 | 792.19 | 671 | 666 | 185.2 |
| C | 12 | 252 | 130895 | 703.04 | 671 | 666 | 185.2 |
| D | 13 | 138 | 12124658 | 95801.52 | 441 | 421 | 126.6 |
| D | 12 | 110 | 909290 | 7181.56 | 441 | 421 | 126.6 |
| D | 2 | 249 | 90666 | 713.08 | 441 | 421 | 126.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
