| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57974cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57974cztM0_level2_quad_clean.evt |
| Size (bytes) | 473,362,560 | 92,499,840 |
| Size | 451.4 MB | 88.2 MB |
| Events in quadrant A | 2,826,475 | 631,697 |
| Events in quadrant B | 3,242,990 | 668,509 |
| Events in quadrant C | 6,244,260 | 523,586 |
| Events in quadrant D | 4,726,837 | 544,404 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12859 | 1 |
| B | 0 | 13860 | 1 |
| C | 0 | 22815 | 2 |
| D | 0 | 18175 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6199 | 53 | 0.854977% |
| B | 6200 | 147 | 2.370968% |
| C | 6199 | 982 | 15.841265% |
| D | 6199 | 273 | 4.403936% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7374 | 6200 | 6 | 6 | 0.08% | 0.10% |  |
| B | 7375 | 6200 | 70 | 70 | 0.95% | 1.13% |  |
| C | 7374 | 6199 | 832 | 832 | 11.28% | 13.42% |  |
| D | 7374 | 6199 | 290 | 290 | 3.93% | 4.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 236 | 39829 | 226.52 | 701 | 682 | 172.8 |
| A | 13 | 248 | 33004 | 187.03 | 701 | 682 | 172.8 |
| A | 3 | 14 | 13554 | 74.48 | 701 | 682 | 172.8 |
| B | 5 | 172 | 201796 | 1368.54 | 685 | 659 | 147.0 |
| B | 6 | 51 | 91828 | 620.31 | 685 | 659 | 147.0 |
| B | 10 | 247 | 36893 | 246.53 | 685 | 659 | 147.0 |
| C | 15 | 224 | 2930324 | 17043.34 | 626 | 621 | 171.9 |
| C | 6 | 223 | 652334 | 3791.29 | 626 | 621 | 171.9 |
| C | 12 | 252 | 93232 | 538.76 | 626 | 621 | 171.9 |
| D | 12 | 110 | 1330476 | 7112.25 | 659 | 631 | 187.0 |
| D | 12 | 251 | 193002 | 1028.83 | 659 | 631 | 187.0 |
| D | 8 | 240 | 127691 | 679.54 | 659 | 631 | 187.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
