| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57977cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57977cztM0_level2_quad_clean.evt |
| Size (bytes) | 571,806,720 | 94,034,880 |
| Size | 545.3 MB | 89.7 MB |
| Events in quadrant A | 3,213,760 | 644,648 |
| Events in quadrant B | 4,267,277 | 686,891 |
| Events in quadrant C | 7,556,797 | 506,756 |
| Events in quadrant D | 5,609,571 | 542,143 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14565 | 2 |
| B | 0 | 17242 | 2 |
| C | 0 | 27124 | 2 |
| D | 0 | 21287 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6693 | 71 | 1.060810% |
| B | 6693 | 150 | 2.241147% |
| C | 6693 | 1393 | 20.812789% |
| D | 6694 | 476 | 7.110846% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7568 | 6694 | 42 | 42 | 0.55% | 0.63% |  |
| B | 7568 | 6694 | 88 | 88 | 1.16% | 1.31% |  |
| C | 7568 | 6694 | 1242 | 1242 | 16.41% | 18.55% |  |
| D | 7569 | 6695 | 446 | 446 | 5.89% | 6.66% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 233424 | 1296.77 | 727 | 708 | 179.5 |
| A | 3 | 245 | 75815 | 418.52 | 727 | 708 | 179.5 |
| A | 8 | 6 | 32723 | 178.4 | 727 | 708 | 179.5 |
| B | 10 | 128 | 1046717 | 6757.66 | 720 | 694 | 154.8 |
| B | 0 | 63 | 80871 | 517.97 | 720 | 694 | 154.8 |
| B | 0 | 157 | 52581 | 335.21 | 720 | 694 | 154.8 |
| C | 15 | 224 | 4978202 | 28497.96 | 632 | 627 | 174.7 |
| C | 12 | 252 | 89603 | 509.41 | 632 | 627 | 174.7 |
| C | 14 | 254 | 12554 | 68.29 | 632 | 627 | 174.7 |
| D | 12 | 110 | 2555885 | 13007.36 | 688 | 658 | 196.4 |
| D | 2 | 31 | 138171 | 700.01 | 688 | 658 | 196.4 |
| D | 5 | 173 | 47323 | 237.55 | 688 | 658 | 196.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
