| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_57989cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_57989cztM0_level2_quad_clean.evt |
| Size (bytes) | 557,913,600 | 86,474,880 |
| Size | 532.1 MB | 82.5 MB |
| Events in quadrant A | 4,150,784 | 597,385 |
| Events in quadrant B | 7,901,253 | 500,869 |
| Events in quadrant C | 4,220,593 | 558,575 |
| Events in quadrant D | 3,909,537 | 538,845 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16491 | 1 |
| B | 0 | 27603 | 1 |
| C | 0 | 16881 | 1 |
| D | 0 | 15747 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6053 | 312 | 5.154469% |
| B | 6053 | 1772 | 29.274740% |
| C | 6053 | 391 | 6.459607% |
| D | 6053 | 162 | 2.676359% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7223 | 6054 | 205 | 205 | 2.84% | 3.39% |  |
| B | 7223 | 6054 | 1445 | 1445 | 20.01% | 23.87% |  |
| C | 7223 | 6054 | 255 | 255 | 3.53% | 4.21% |  |
| D | 7223 | 6054 | 105 | 105 | 1.45% | 1.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 1462342 | 8627.3 | 678 | 660 | 169.4 |
| A | 3 | 14 | 22620 | 129.61 | 678 | 660 | 169.4 |
| A | 3 | 245 | 20966 | 119.85 | 678 | 660 | 169.4 |
| B | 10 | 128 | 5255313 | 40891.54 | 596 | 575 | 128.5 |
| B | 4 | 171 | 48108 | 369.89 | 596 | 575 | 128.5 |
| B | 0 | 171 | 37694 | 288.85 | 596 | 575 | 128.5 |
| C | 15 | 224 | 1141009 | 6441.2 | 645 | 639 | 177.0 |
| C | 15 | 201 | 306881 | 1729.76 | 645 | 639 | 177.0 |
| C | 14 | 254 | 187442 | 1055.13 | 645 | 639 | 177.0 |
| D | 12 | 110 | 822654 | 4410.14 | 651 | 623 | 186.4 |
| D | 2 | 31 | 147981 | 790.57 | 651 | 623 | 186.4 |
| D | 5 | 32 | 103807 | 553.58 | 651 | 623 | 186.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
