| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_58070cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_58070cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,427,745,600 | 197,861,760 |
| Size | 1.3 GB | 188.7 MB |
| Events in quadrant A | 6,907,883 | 1,400,883 |
| Events in quadrant B | 15,078,429 | 1,302,828 |
| Events in quadrant C | 10,343,196 | 1,252,405 |
| Events in quadrant D | 19,366,244 | 1,001,446 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31882 | 1 |
| B | 0 | 55175 | 1 |
| C | 0 | 41557 | 1 |
| D | 0 | 68045 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 302 | 0 |
| B | 0 | 302 | 0 |
| C | 0 | 302 | 0 |
| D | 0 | 302 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 14953 | 172 | 1.150271% |
| B | 14954 | 2245 | 15.012706% |
| C | 14954 | 1109 | 7.416076% |
| D | 14954 | 3559 | 23.799652% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 15268 | 14954 | 36 | 36 | 0.24% | 0.24% |  |
| B | 15269 | 14955 | 1210 | 1210 | 7.92% | 8.09% |  |
| C | 15269 | 14955 | 843 | 843 | 5.52% | 5.64% |  |
| D | 15269 | 14955 | 3250 | 3250 | 21.28% | 21.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 404671 | 990.27 | 1663 | 1624 | 407.0 |
| A | 13 | 248 | 42009 | 99.22 | 1663 | 1624 | 407.0 |
| A | 13 | 254 | 22715 | 51.82 | 1663 | 1624 | 407.0 |
| B | 10 | 128 | 4762332 | 13947.71 | 1574 | 1508 | 341.3 |
| B | 5 | 172 | 3242247 | 9494.34 | 1574 | 1508 | 341.3 |
| B | 4 | 171 | 265231 | 772.63 | 1574 | 1508 | 341.3 |
| C | 12 | 252 | 2249346 | 5302.78 | 1564 | 1552 | 423.9 |
| C | 12 | 254 | 1290975 | 3041.88 | 1564 | 1552 | 423.9 |
| C | 15 | 201 | 321567 | 754.95 | 1564 | 1552 | 423.9 |
| D | 12 | 110 | 8467657 | 20557.28 | 1485 | 1425 | 411.8 |
| D | 2 | 120 | 1304325 | 3163.64 | 1485 | 1425 | 411.8 |
| D | 15 | 94 | 1122847 | 2722.98 | 1485 | 1425 | 411.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
