| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_58075cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_58075cztM0_level2_quad_clean.evt |
| Size (bytes) | 668,399,040 | 86,719,680 |
| Size | 637.4 MB | 82.7 MB |
| Events in quadrant A | 3,146,392 | 641,862 |
| Events in quadrant B | 4,542,951 | 667,839 |
| Events in quadrant C | 4,586,714 | 587,020 |
| Events in quadrant D | 11,978,613 | 290,446 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13521 | 1 |
| B | 0 | 17690 | 1 |
| C | 0 | 17906 | 1 |
| D | 0 | 39935 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6279 | 82 | 1.305940% |
| B | 6280 | 315 | 5.015924% |
| C | 6280 | 385 | 6.130573% |
| D | 6280 | 3433 | 54.665605% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7449 | 6280 | 29 | 29 | 0.39% | 0.46% |  |
| B | 7450 | 6281 | 187 | 187 | 2.51% | 2.98% |  |
| C | 7450 | 6281 | 379 | 379 | 5.09% | 6.03% |  |
| D | 7450 | 6281 | 3099 | 3099 | 41.60% | 49.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 183440 | 1030.13 | 718 | 699 | 177.4 |
| A | 3 | 14 | 64363 | 358.88 | 718 | 699 | 177.4 |
| A | 13 | 248 | 54387 | 302.64 | 718 | 699 | 177.4 |
| B | 10 | 128 | 1355779 | 9067.54 | 693 | 670 | 149.4 |
| B | 4 | 171 | 88422 | 587.18 | 693 | 670 | 149.4 |
| B | 2 | 249 | 74714 | 495.46 | 693 | 670 | 149.4 |
| C | 12 | 252 | 1683487 | 9067.81 | 674 | 667 | 185.6 |
| C | 12 | 254 | 129591 | 694.7 | 674 | 667 | 185.6 |
| C | 15 | 201 | 50908 | 270.72 | 674 | 667 | 185.6 |
| D | 12 | 110 | 5511797 | 36461.96 | 536 | 512 | 151.2 |
| D | 8 | 160 | 1747596 | 11558.48 | 536 | 512 | 151.2 |
| D | 2 | 120 | 1296900 | 8576.74 | 536 | 512 | 151.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
