| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_031T01_9000006584_58082cztM0_level2.fits | modeM0/AS1A14_031T01_9000006584_58082cztM0_level2_quad_clean.evt |
| Size (bytes) | 716,425,920 | 108,417,600 |
| Size | 683.2 MB | 103.4 MB |
| Events in quadrant A | 5,282,038 | 722,660 |
| Events in quadrant B | 11,620,784 | 581,963 |
| Events in quadrant C | 3,781,914 | 723,286 |
| Events in quadrant D | 5,186,583 | 674,093 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21972 | 1 |
| B | 0 | 40277 | 0 |
| C | 0 | 17610 | 0 |
| D | 0 | 21352 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 166 | 0 |
| B | 0 | 166 | 0 |
| C | 0 | 166 | 0 |
| D | 0 | 166 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8357 | 545 | 6.521479% |
| B | 8357 | 2733 | 32.703123% |
| C | 8357 | 28 | 0.335048% |
| D | 8358 | 223 | 2.668102% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8538 | 8536 | 390 | 390 | 4.57% | 4.57% |  |
| B | 8538 | 8536 | 2071 | 2071 | 24.26% | 24.26% |  |
| C | 8538 | 8536 | 20 | 20 | 0.23% | 0.23% |  |
| D | 8539 | 8537 | 196 | 196 | 2.30% | 2.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 1757290 | 7930.9 | 903 | 879 | 221.5 |
| A | 13 | 254 | 13633 | 57.59 | 903 | 879 | 221.5 |
| A | 4 | 3 | 13495 | 56.97 | 903 | 879 | 221.5 |
| B | 10 | 128 | 7946955 | 46865.93 | 793 | 762 | 169.6 |
| B | 2 | 249 | 174884 | 1026.96 | 793 | 762 | 169.6 |
| B | 4 | 201 | 126655 | 742.51 | 793 | 762 | 169.6 |
| C | 12 | 252 | 118749 | 485.29 | 893 | 886 | 242.9 |
| C | 12 | 254 | 71605 | 291.18 | 893 | 886 | 242.9 |
| C | 15 | 201 | 37236 | 149.67 | 893 | 886 | 242.9 |
| D | 12 | 1 | 715716 | 2886.85 | 880 | 844 | 247.6 |
| D | 12 | 110 | 402795 | 1623.19 | 880 | 844 | 247.6 |
| D | 2 | 249 | 189096 | 760.21 | 880 | 844 | 247.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
