| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58104cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58104cztM0_level2_quad_clean.evt |
| Size (bytes) | 903,110,400 | 66,623,040 |
| Size | 861.3 MB | 63.5 MB |
| Events in quadrant A | 3,687,080 | 643,851 |
| Events in quadrant B | 11,972,980 | 251,338 |
| Events in quadrant C | 3,234,990 | 618,820 |
| Events in quadrant D | 14,042,800 | 60,971 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15220 | 1 |
| B | 0 | 39900 | 1 |
| C | 0 | 13866 | 1 |
| D | 0 | 45928 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6342 | 208 | 3.279722% |
| B | 6343 | 4387 | 69.162857% |
| C | 6342 | 101 | 1.592558% |
| D | 6342 | 5831 | 91.942605% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7442 | 6342 | 95 | 95 | 1.28% | 1.50% |  |
| B | 7443 | 6343 | 3863 | 3863 | 51.90% | 60.90% |  |
| C | 7442 | 6342 | 25 | 25 | 0.34% | 0.39% |  |
| D | 7441 | 6341 | 5350 | 5350 | 71.90% | 84.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 711375 | 3869.09 | 741 | 720 | 183.7 |
| A | 6 | 195 | 45071 | 241.46 | 741 | 720 | 183.7 |
| A | 3 | 61 | 20455 | 107.45 | 741 | 720 | 183.7 |
| B | 5 | 172 | 8050664 | 70405.97 | 529 | 509 | 114.3 |
| B | 10 | 128 | 1569272 | 13720.27 | 529 | 509 | 114.3 |
| B | 5 | 185 | 57535 | 498.74 | 529 | 509 | 114.3 |
| C | 12 | 252 | 260728 | 1317.76 | 718 | 710 | 197.3 |
| C | 6 | 223 | 54713 | 273.68 | 718 | 710 | 197.3 |
| C | 9 | 38 | 40375 | 201.02 | 718 | 710 | 197.3 |
| D | 12 | 110 | 12058115 | 106129.72 | 396 | 377 | 113.6 |
| D | 8 | 160 | 200789 | 1763.99 | 396 | 377 | 113.6 |
| D | 2 | 249 | 95250 | 835.05 | 396 | 377 | 113.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
