| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58119cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58119cztM0_level2_quad_clean.evt |
| Size (bytes) | 586,437,120 | 80,991,360 |
| Size | 559.3 MB | 77.2 MB |
| Events in quadrant A | 2,822,060 | 612,628 |
| Events in quadrant B | 4,286,051 | 624,958 |
| Events in quadrant C | 2,922,769 | 575,850 |
| Events in quadrant D | 11,213,651 | 222,793 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12421 | 1 |
| B | 0 | 16531 | 1 |
| C | 0 | 12727 | 1 |
| D | 0 | 37276 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5955 | 78 | 1.309824% |
| B | 5955 | 442 | 7.422334% |
| C | 5955 | 106 | 1.780017% |
| D | 5956 | 3801 | 63.817999% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7095 | 5956 | 7 | 7 | 0.10% | 0.12% |  |
| B | 7095 | 5956 | 338 | 338 | 4.76% | 5.67% |  |
| C | 7095 | 5956 | 53 | 53 | 0.75% | 0.89% |  |
| D | 7096 | 5957 | 3425 | 3425 | 48.27% | 57.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 70294 | 408.34 | 694 | 675 | 170.5 |
| A | 11 | 3 | 37120 | 213.77 | 694 | 675 | 170.5 |
| A | 3 | 245 | 16985 | 95.67 | 694 | 675 | 170.5 |
| B | 10 | 128 | 1394872 | 9741.02 | 665 | 641 | 143.1 |
| B | 0 | 153 | 34258 | 234.87 | 665 | 641 | 143.1 |
| B | 5 | 185 | 30156 | 206.21 | 665 | 641 | 143.1 |
| C | 12 | 2 | 180202 | 991.58 | 663 | 656 | 181.1 |
| C | 1 | 16 | 80119 | 438.85 | 663 | 656 | 181.1 |
| C | 11 | 244 | 27581 | 148.7 | 663 | 656 | 181.1 |
| D | 12 | 110 | 8876989 | 62149.79 | 500 | 479 | 142.8 |
| D | 7 | 222 | 152350 | 1063.34 | 500 | 479 | 142.8 |
| D | 2 | 249 | 46368 | 321.3 | 500 | 479 | 142.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
