| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58140cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58140cztM0_level2_quad_clean.evt |
| Size (bytes) | 953,089,920 | 88,917,120 |
| Size | 908.9 MB | 84.8 MB |
| Events in quadrant A | 3,857,547 | 761,218 |
| Events in quadrant B | 19,756,324 | 44,741 |
| Events in quadrant C | 3,596,983 | 718,847 |
| Events in quadrant D | 7,456,249 | 618,126 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17126 | 0 |
| B | 0 | 64094 | 5 |
| C | 0 | 16642 | 0 |
| D | 0 | 27561 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7902 | 64 | 0.809922% |
| B | 7901 | 7536 | 95.380332% |
| C | 7901 | 32 | 0.405012% |
| D | 7902 | 864 | 10.933941% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7902 | 7902 | 57 | 57 | 0.72% | 0.72% |  |
| B | 7900 | 7900 | 7185 | 7185 | 90.95% | 90.95% |  |
| C | 7901 | 7901 | 26 | 26 | 0.33% | 0.33% |  |
| D | 7902 | 7902 | 833 | 833 | 10.54% | 10.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 179503 | 835.24 | 863 | 843 | 213.9 |
| A | 10 | 251 | 178815 | 832.02 | 863 | 843 | 213.9 |
| A | 11 | 3 | 74322 | 343.52 | 863 | 843 | 213.9 |
| B | 10 | 128 | 18728519 | 424978.99 | 199 | 192 | 44.1 |
| B | 2 | 249 | 130502 | 2956.97 | 199 | 192 | 44.1 |
| B | 5 | 185 | 57939 | 1310.38 | 199 | 192 | 44.1 |
| C | 12 | 252 | 185247 | 809.07 | 831 | 824 | 227.9 |
| C | 12 | 250 | 34247 | 146.63 | 831 | 824 | 227.9 |
| C | 9 | 38 | 32430 | 138.66 | 831 | 824 | 227.9 |
| D | 12 | 110 | 2799949 | 12384.84 | 797 | 763 | 226.0 |
| D | 8 | 160 | 478466 | 2113.57 | 797 | 763 | 226.0 |
| D | 8 | 240 | 381719 | 1685.52 | 797 | 763 | 226.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
